- Page 1 Horizontal Web lifeline Instruction Manual Read and understand instructions before using this equipment Do not throw instructions away Designed in the UK SHUM-051 Iss 02...
- Page 2 Contents Limitations, About & Warning Description Using the Device Compatibility 18 19 Service Log Inspection Table Declaration Labelling Conformity...
- Page 3 Product Maintenance, Safe Use Specification Servicing & Storage Notes...
- Page 4 ABOUT & WARNING shall provide instructions for use, SafeHold Webbing maintenance, periodic Temporary Horizontal Lifeline examination and for repair in the language of the country in which This manual covers all variants the product is to be used. within the lifeline range.
- Page 5 Risk Statement independently assessed to meet The horizontal lifeline is designed the requirements of EN 795:2012 to protect against falls from height Type C (for 1 user) and PD CEN/ of up to four users by providing TS 16415:2013 Type B & C (for an anchorage for the attachment 4 users), although this is outside of the Module B certification.
- Page 6 APPLICATIONS & USING THE LIFELINE with slopes up to 4/12 (vertical/ Personal Fall Arrest: horizontal). Web HLL may be used to support a MAXIMUM 4 Personal Fall Arrest System (PFAS) for use in Fall WARNING ! The Competent Person must Arrest applications.
- Page 7 EN362 in-line/parallel with the Web HLL lifeline. Full Body Harnesses in accordance with EN361 Anchorage Connectors Safehold Fall Arrest Blocks in SafeHold equipment is designed accordance with EN360 for use with SafeHold approved components subsystems Anchor slings in accordance with only.
- Page 8 2 users: 2.65m 4 users: 3.25m The Web HLL is recommended for compliant with EN355:2002 (& use with the following products. EN354:2010 applicable). • Please contact SAFEHOLD with Restraint lanyard compliant with questions relating product EN354:2010 (& EN358:2018 if compatibility.
- Page 9 COMPATIBILITY Compatibility: When making Warning!: If the user weighs connections with HLL, between 100kg-140kg, check all eliminate all possibility of roll-out. PPE equipment in the personal fall Roll-out occurs when interference arrest system for use in fall arrest, between a hook and the attachment restraint or work positioning is point causes the hook gate to rated to the increased max user...
-
Page 10: Product Specification
• Connector/ratchet material: zinc plated steel • Webbing width: 35mm • System weight: 4.85kg Prior to Installation: ONLY use approved SAFEHOLD products. The use of unapproved Ensure the area beneath and devices may impair the system around free from performance and safety. - Page 11 INSTALLATION & SAFE USE 1. Web HLL should only be installed horizontally and NOT at any other angle. 2. Web HLL should not be used in combination with pass-through anchors. 3. Determine correct system length (maximum 20m) and anchor point installation locations.
- Page 12 INSTALLATION & SAFE USE System components Storage Bag, 2 x anchor straps, 20m web lifeline and tensioner. 4 x connection rings.
- Page 13 Servicing: The Web Lifeline is a returned to Safehold for energy recovery. The equipment could still non-serviceable item and must be misused and we do promote be destroyed and disposed of safe and sustainable disposal only.
- Page 14 Certification brought into UK law and amended, Services Limited, Block and the following standards. Blanchardstown Corporate Park, Safehold Anchor range Ballycoolin Road, Blanchardstown, has been designed to meet the Dublin 15 D15 AKK1, Ireland requirements of EN795:2012 as a (NB2834).
- Page 15 SAFEY NOTICE & WARNINGS! Failure to understand and comply with safety regulations could result in serious injury or death. Equipment Handling: Please refrain from altering or misusing any equipment. Workplace Assessment: A Competent Person must evaluate workplace conditions, which may include but are not limited to factors like high temperatures, corrosive chemicals, electrical hazards, sharp objects, machinery, uneven surfaces, UV exposure, and adverse weather conditions.
- Page 16 The user must inspect prior to EACH use. Designed in the UK by: Competent Person must complete formal Safehold Ltd inspection every 12 months. A Competent 1-3 Eaves Court Bonham Drive, Person MUST inspect and initial.
-
Page 17: Service Log
SERVICE LOG Safehold LTD www.safe-hold.com Model #: User: Date of first use: Serial No: Date of manufacture: Pass Fail Date Results/Condition: Inspected by: Next Inspection Date:... - Page 18 Competent Component Inspection: User Person Ensure webbing is free from cuts, abrasion, wear and tear and deployment. Check the weave of the Webbing webbing for distortion resulting from loading. Melted webbing or any other signs of either heat or chemical exposure Sewing / Any loose / damaged / thread...
-
Page 19: Eu Declaration Of Conformity
EU DECLARATION OF CONFORMITY This declaration of conformity is issued under the sole responsibility of the manufacturer: SAFEHOLD LTD: 1-3 Eaves Court Bonham Drive, Sittingbourne, ME10 3RY. compliance@safe-hold.com +44 (0) 1795 668862 Model No. 31603 Product Description Code 31603 Web Lifeline SHWTL-01 Temporary Web Lifeline Kit 20m... - Page 20 www.safe-hold.com...
