Thermal Gas Systems Haloguard III Checklist

e-mail: thermalgas@mindspring.com
Thermal Gas inc.
11285 Elkins Road Bldg. H-1 • P.O. Box 803 • Roswell, GA 30076
TEL (770) 667-3865
® ® ® ® ® ® ® ®
Haloguard and Haloguard IR Monitors
FAX (770) 667-3857
Please Visit our web site at www.thermalgas.com.
® ® ® ®
Haloguard III or IR Refrigerant Monitor
AUTHORIZED FACTORY REPRESENTATIVE
START-UP/FINAL INSPECTION CHECKLIST
Model#___________________________
Serial# ___________________________
PRIOR TO START-UP
INSTALLATION INSPECTION
1. Ensure that the monitor is securely mounted to the wall or support approximately five feet off the
floor using the four (4) mounting holes.
Findings and any Corrective action taken:
__________________________________________________________________________________
2. Ensure that sample pick-up tubes are located near potential leaks in a quiet area or downstream
from leak source in area with air movement and that there are no kinks in the tubing.
Findings and any Corrective action taken:
___________________________________________________________________________________________
3. Ensure sample tube is located 18" - 24" above the finished floor and that the area is not subject to
flooding, potential impact, or severe ambient temperature or humidity changes.
Findings and any Corrective action taken:
___________________________________________________________________________________________
4. Ensure end-of-line filter assemblies are in place and that the white porous filter has not been painted
over, damaged or clogged in any way.
Findings and any Corrective action taken:
___________________________________________________________________________________________
CONNECTIONS INSPECTION
5. Perform the following tests with power off.
Remove outside cover (4 screws), then remove metal power cover in lower left hand corner of unit (3
screws). Visually inspect that the line cord has been wired correctly, Black to L, Green to G and White
to N. Visually inspect the fuse.
Findings and any Corrective action taken:
___________________________________________________________________________________________
6. Inspect for loose (clipped) wire strands that could cause the system to short. Gently blow out
construction debris from instrument with compressed air if available. Check all screw terminals for
tightness.
Findings and any Corrective action taken:
___________________________________________________________________________________________
1
Rev. 12/10 FINAL INSPECT CHLST rev3.doc
