HALOGUARD II CMOS REFRIGERANT MONITOR
AUTHORIZED FACTORY REPRESENTATIVE
START-UP/FINAL INSPECTION CHECKLIST
PRIOR TO START-UP
INSTALLATION INSPECTION
1. Ensure that the monitor is securely mounted to the wall or support, approximately five feet off
the floor using the four (4) mounting holes.
Findings and any Corrective action taken:
_______________________________________________________________________________________
2. Ensure that the sensors are located near potential leaks in a quiet area or downstream from
leak source in area with air movement and that there are no kinks in the sensor wiring. Ensure that
sample pick-up tubes are located near potential leaks in a quiet area or downstream from leak
source in area with air movement and that there are no kinks in the tubing.
Findings and any Corrective action taken:
_______________________________________________________________________________________
3. Ensure that the sample tubes are located approximately 18" - 24" above the finished floor and
that the area is not subject to flooding, potential impact or severe ambient temperature or humidity
changes.
Findings and any Corrective action taken:
_______________________________________________________________________________________
4. Ensure end-of-line filter assemblies are in place and that the white porous filter has not been
painted over, damaged or clogged in any way.
Findings and any Corrective action taken:
_______________________________________________________________________________________
CONNECTIONS INSPECTION
5. Perform the following tests with power off. Remove lower cover (2 screws). Visually inspect
that the sensor cables have been wired correctly, Red to +V, White to SIG and Black to GND.
Findings and any Corrective action taken:
_______________________________________________________________________________________
6. Inspect for loose wire strands that could cause the system to short. Gently blow out construction
debris from instrument with compressed air if available. Check all screw terminals for tightness.
Findings and any Corrective action taken:
_______________________________________________________________________________________
1
Rev. 1.00 06/07
FINAL INSPECT CHLST II CMOS.rev1.DOC
