- Page 1 Bedienungsanleitung Operating Instructions ExOn2, DX303 ExOn2-5, DX311 Extrusionstechnik GmbH Dohle Eitorfer Strasse 1 D – 53809 Ruppichteroth www.dohle-extruder.de...
-
Page 2: Table Of Contents
Operating Instructions DOHLE Hand Welding Extruder ExOn2 We retain all copyrights of all descriptions, drawings and schedules contained in these operating instructions which may not be reproduced nor be made accessible by third parties or by competitors, neither in whole nor in part, unless we have expressly consented thereto. -
Page 3: Description Of Type
Operating Instructions DOHLE Hand Welding Extruder ExOn2 1. Type Article-no. / Type of machine : DX303 ExOn2, DX311 ExOn2-5 ..Machine no. Required voltage 230 V / 50 – 60 Hz Heating unit 2700 W/11,7A 2. Safety Pursuant to section 55 of VDE 0 100 (Regulations of the Association of German Electrotechnical Engineers), the extruder must be operated using a protective switch or an isolation transformer. - Page 4 Operating Instructions DOHLE Hand Welding Extruder ExOn2 Operation: Never use hand-held welding and extruding machines without air supply. In case of external air supply ensure that the feed line is of sufficient size. The pressurised air that is supplied must be free of oil and water.
-
Page 5: Start-Up
Operating Instructions DOHLE Hand Welding Extruder ExOn2 3. Start-up General: Observe the notes on safety contained in these operating instructions. In addition, the regulations on the prevention of accidents and the national regulations shall apply. Assembling the hand-held welding and extruding machine When dispatched, our hand-held welding and extruding machines are almost completely assembled. - Page 6 View – controller front – steering box standard optional D - 2378 controller extruder ExOn2 D - 2377 temperature controller ExOn2-6 air D - 2384 switch heater ExOn2-6 D - 2383, poti ExOn2-6 D - 2383 poti ExOn2-6 air flow...
- Page 7 Operating Instructions DOHLE Hand Welding Extruder ExOn2 Change of the welding shoe In order to be sure that no more old welding rod is in the hand welding extrusion, heat up the machine on operating temperature, remove the welding shoe and change the nozzle (note: left hand thread!).
-
Page 8: Error Tracing
Operating Instructions DOHLE Hand Welding Extruder ExOn2 4. Error tracing Malfunctioning Error– No. Driving motor does not start 01,02,04,05,06,07,08,09,10,11,12 Driving motor switches off 03,04,05,06,07,08,09,10 Extruder remains cold 04,05,06,07,08,09,15,17 Hot air remains cold 05,07,08,09,12 Hot air temperature is under 11,13 desired value... -
Page 9: Drawings, Informations
Operating Instructions DOHLE Hand Welding Extruder ExOn2 5 Drawings, Informations DX303 ExOn2, DX311 ExOn2-5 DOHLE Extrusionstechnik GmbH... - Page 10 Operating Instructions DOHLE Hand Welding Extruder ExOn2 a rtic le - n o d e s c rip tio n q ty 6 6 0 0 6 4 6 a n g le d h o s e s c re w fittin g...
- Page 11 Operating Instructions DOHLE Hand Welding Extruder ExOn2 Eron ExOn2-6, Art-No: D -1664 DOHLE Extrusionstechnik GmbH...
- Page 12 Operating Instructions DOHLE Hand Welding Extruder ExOn2 article-no description 5101270 gasket 70x48x4 5101760 mica tube 47,6x95 5113268 heating element 230V/2200W 6100284 countersunk screw M4x12 TX 6100287 hexagon nut M5 6113695 temperatur limit switch 135°C 6600596 thermoelement 6600601 air filter 6600606...
- Page 13 Operating Instructions DOHLE Hand Welding Extruder ExOn2 Spare Parts Drive Unit DB045 DOHLE Extrusionstechnik GmbH...
- Page 14 Operating Instructions DOHLE Hand Welding Extruder ExOn2 Art.Nr. Description DB046 Gear BSM 274 DB004 Idler 8Z DB005 Gearwheel 21 Z DB006 Flat Gasket DB007 Cylinder Pin 4m6, 6x16 DIN7 DB008 Engine Flap KPL DB009 Ball Bearing 6000 C3 2 RS...
- Page 15 Operating Instructions DOHLE Hand Welding Extruder ExOn2 DOHLE Extrusionstechnik GmbH...
- Page 16 Operating Instructions DOHLE Hand Welding Extruder ExOn2 Welding Shoes s = thickness of material fillet weld corner weld a = s x 0,7 thickness of material order - no. D-0195 10-12 D-0196 thickness of material order - no. D-0197 D-0174...
