6 SERIES
EXHAUST DUCT INSTALLATION GUIDE
When ducting the unit, a dedicated duct system is recommended for each unit.
Recommended 25' max run of ducting.
1
USE RECTANGUL AR DUCT.
RECTaNGULaR DUCTING
a. aTTaCH ITEM 2 (DUCT aDaPTER) TO ITEM 1 (UNIT)
USING 10 OF ITEM 4 (SCREWS)
b. aTTaCH RECTaNGULaR DUCTING (NOT PROVIDED)
DIRECTLY TO ITEM 2 (DUCT aDaPTER).
www.QuestClimate.com
1.877.420.1330
Air can be distributed from the unit in two ways:
ITEM 1 6 SERIES DEHUMIDIFIER
ITEM 2a DUCT aDaPTER
ITEM 2b
ITEM 3 12" COLLaR PLaTE
ITEM 4
2
USE 2-12" ROUND DUCTS.
*CAUTION - OPTION 2 CAN ONLY BE USED ON QUEST 506.
2-12" ROUND DUCTS
a. aTTaCH ITEM 2 (DUCT aDaPTER) TO ITEM 1 (UNIT)
USING 10 OF ITEM 4 (SCREWS)
b. aTTaCH ITEM 3 (12" COLLaR PLaTE) TO ITEM 2
(DUCT aDaPTER) USING 12 OF ITEM 4 (SCREWS)
C. aTTaCH 12" DUCT (NOT PROVIDED) TO bOTH 12" DUCT
COLLaRS.
(506 ONLY)
DUCT aDaPTER
(506 ONLY)
#10 SCREWS
QTY
Not Provided
1
1
1
22
TS-1063
05/19 Rev. E
