EK 2020-D-US
Information Systems |
Product Description
The EK 2020-D-US is a rugged digital RF bodypack receiver that operates in the
926–928 MHz frequency range. The receiver features six channels, as standard, and
may be programmed to eight channel operation (with the L2021-40 charger).
Intuitive operating controls make it easy to use.The internal lithium polymer battery
offers 16 hours of battery life. The 3.5mm audio output allows connection of
standard headphones, or an induction neckloop for telecoil-equipped hearing aids.
Features
Digital RF signal transmission
Intuitive operation
16 hours battery life
3.5 mm audio output for headphones or induction neckloop
Backlit LC display
Rugged housing
Delivery Includes: 1 EK 2020-D-US, 1 operating manual
Product Variants
K E
2
0
2
0
D -
K E
2
0
2
0
D -
U -
S
Recommended Accessories
E
L Z
2
0
2
0
2 -
0 Charger case
2 L
0
2
1
4 -
0
Rack-mountable charger
E
T Z
3
0
1
2 Induction neckloop
Digital bodypack receiver
TG 2020-D
Guided tours, Assistive Listening, Conference
a C
. t
N
o
5 .
0
2
a C
. t
N
o
5 .
0
2
a C
. t
N
o
5 .
0
0
a C
. t
N
o
5 .
0
2
a C
. t
N
o
5 .
0
4
Technical Data
Modulation ......................................................................2 FSK
RF frequency range ..................................... 926 – 928 MHz
Number of channels (tourguide mode) ........................... 6
Number of channels (conference mode) ......................... 8
THD, total harmonic distortion ............... < 1 % at 10 mW
Headphone connector .................... Max. 10 mW /32 Ohm
Operating time (battery) ............................... approx. 16 h
Voltage Lithium polymer batterie ................... 1500 mAh
Operating temperature ..................................... 32 – 122°F
Dimensions ............................................... 3.85 x 2.4 x 0.9 in.
Weight incl. battery ...................................approx. 2.75 oz.
Architect & Engineering specs (Profile)
A digital RF bodypack receiver utilizing the frequency
range of 926–928 MHz. It provides two operation
modes; tourguide and conference mode. In mobile
tourguide mode, up to 6 channels shall be usable in
parallel.
In stationary conference mode, up to 8
channels shall be usable in parallel. The volume wheel is
easy to access and to control. A backlit LC display
indicates battery status, signal strength, channel and
volume settings. A clip allows the receiver to be worn on
clothing or a lanyard. The internal rechargeable battery
0
3
5
provides an operating time of 16 hours. The weight
0
3
6
including the battery may not exceed 2.75 oz. The
bodypack receiver shall be Sennheiser EK 2020-D-US.
5
4
2
0
3
7
0
6
1
Cat.-No. 502036
