This is Franka Hand an electrical two-finger parallel gripper produced by Franka Robotics. No external cabling is needed. Communication and power supply for the Franka Hand is established via the flange connector of the Arm. Figure 2.1: Overview Franka Hand...
The responsible person is not granted any rights or claims to the trademark, logo, or trade names of Franka Robotics. Use of open-source codes A complete list of all open-source licenses used by compatible Robots of Franka Robotics can be accessed via the settings menu of the Franka UI. 3.2 Identification...
Franka Handling, or mounting. Franka Hand may only be used in sound technical condition, for its intended purpose and within the technical specifications and operating conditions, with awareness of safety and possible dangers.
Enwrapping the robotic structure It is prohibited to open the Franka Hand enclosure and other equipment. Franka Robotics is not liable for damages caused by mounted, grasped or lost equipment or damages caused by misuse. 4.5 General Possible Dangers and Safety Measures when...
Carry out a risk assessment and implement the measures resulting from it. Gripping of an object at a distance of the finger to the Franka Hand will lead to tilting loads. The Franka Hand is designed and tested for a finger length of 54 mm.
Figure 6.1: Franka Hand Also included: 1 set of fingertips 2 x DIN7984 M6x12 ST 8.8 screws 1 x ISO2338B Ø6x10 h8 A2 cylindrical pin Quick Guide for Installation Franka Hand Figure 6.2: Additional material Additional required equipment: • Hex key size 4 •...
Objects or tools could fall at any time (e.g., due to loose couplings, malfunctions that can cause the Franka Hand to open or when a compatible robot of Franka Robotics is switched off, or the power to the robot system is cut) which could lead to injury to fingers, Franka Hands, toes, and feet.
Figure 7.1: Mounting of Franka Hand If desired, insert the cylindrical pin in the Ø6H7 fit of the flange of the Franka Hand. Should you not use the cylindrical pin, make sure that the side of the Franka Hand with the cable is aligned to the side of the flange where the connector is located.
Page 20
Connecting or disconnecting live cables or connectors during operation may lead to damaging the Arm or the Franka Hand. Do not connect or disconnect the Franka Hand while a compatible robot of Franka Robotics is not safely disconnected from the mains power supply.
Franka Hand can be selected from a dedicated dropdown menu. Figure 7.3: Screenshot Power Status If you want to use another gripper or adjust the configuration of the Franka Hand, select “User Defined” from the drop-down menu and enter the corresponding values into the text fields. R50010/1.0/EN...
The tracking behavior may be affected. For further information, refer to the Franka Production product manual. If you are looking to attach additional tools between the Franka Hand and flange and therefore require a longer connection cable, see chapter 14 ADDITIONAL INFORMATION.
INSTALLATION 7.3.2 Integration in Watchman When using the Franka Hand on compatible Franka robots, the settings for the monitoring safety functions in Watchman must be adjusted. The safety behavior of the connected end effector is defined via the "End Effector Configuration". The following fields can be set: •...
INSTALLATION Figure. 7.7: Coordinate System of Flange Below, an example of the sphere configuration of the Franka Hand is shown. Figure. 7.8: Example of spheres for Franka Hand If your gripping situation is not covered by the spherical model shown above, it must be adapted. Make sure that contours that could lead to collisions are covered by the sphere model.
INSTALLATION The following illustration shows an example of the Franka hand with a gripped rod. The spheres (yellow and purple) at the ends of the rod ensure that the maximum speed at the end of the rod is monitored. Figure. 7.9: Example of sphere configuration Franka hand with a rod R50010/1.0/EN...
Do not use liquid cleaning agents for cleaning the end effector. 8.2 Disposal Disposal Disposal of Franka Hand may only take place according to the relevant country-specific laws, standards, and regulations. Return of packaging waste Please contact Franka Robotics to process any returns of packaging waste.
If you have purchased your compatible Franka robot at one of our sales partners or if you have cooperated with a service provider, please get in contact with them first. Our partners can consolidate information on our products and reach out to Franka Robotics for troubleshooting and further support. Please visit https://franka.world...
Objects or tools could fall at any time (e.g., due to loose couplings). Malfunctions that can cause the Franka Hand to open or when a compatible robot is switched off, or the power to robot system is cut) which could lead to injury to fingers, Franka Hands, toes, and feet.
CUSTOMIZING 12 CUSTOMIZING Use Franka Robotics 3D Lab to customize fingertips. 3D Lab is a web-based user interface to design 3D- printable fingertips, for an ideal, ad hoc object grip with your Franka Hand. Access Franka Robotics 3D Lab from https://world.franka.de/fingertip-configurator.
If the Franka Hand is still disconnected: Shut down the robot. Check if the Franka Hand is connected properly or if any damages on the pins of the connector can be seen. Also check the connecting cable between Control and Arm for damaged pins or insufficient mounting.
ADDITIONAL INFORMATION 14 ADDITIONAL INFORMATION 14.1 Extending the connector cable To add an equipment mounting flange between Franka Hand and flange, extend the connector cable by adding an extension cable. Figure 14.1: Electric Connection A Binder 8-pin male/female connection: Snap-in IP67 Series 620 is required.
