Sennheiser Evolution E 602 Product Sheet

Microphones |
General Description
The e 602 is a cardioid microphone especially suitable for use with bass
drums, bass guitar cabs, tubas and other low frequency instruments.
Features
Rugged metal body
Lightweight, high-performance voice coil construction with
large diaphragm design
Fast transient response
Low frequency extension
Ideal for direct use on the most problematic bass signal sources
Frequency-independent directivity provides isolation from
other on-stage signals
Hum compensating coil
Integral stand mount
Delivery includes: 1 e 602
1 pouch
Dynamic Microphone
Technical Data
Pick-up pattern ...................................................................... cardioid
Frequency response ................................................. 20 – 16,000 Hz
Sensitivity (free field, no load, 1 kHz)...........................1.0 mV/Pa
Nominal impedance ................................................................. 250 Ω
Min. terminating impedance ..................................................... 1 kΩ
Dimensions ................................................................ Ø 60 x 153 mm
Weight ........................................................................................ 550 g
Profile
Cardioid instrument microphone, hum compensating coil,
frequency response 20 Hz – 16 kHz, sensitivity (free field,
no load) 1.0 mV/Pa at 1 kHz, nominal impedance 250 Ω, min.
terminating impedance 1 kΩ, dimensions Ø 60 x 153 mm,
weight 550 g.
Cat. No. 004521
