- Page 1 Kit Instructions SDS Server Solid-State Drive (SSD) 1616-K005/K006/K007/K008/K009/K010 Issue A...
- Page 2 NCR, therefore, reserves the right to change specifications without prior notice. All features, functions, and operations described herein may not be marketed by NCR in all parts of the world. In some instances, photographs are of equipment prototypes. Software screen images are representative, and in some cases, may not match a customer’s installed software exactly.
-
Page 3: Revision Record
Revision Record Issue Date Remarks Feb 2021 First Issue... - Page 4 SDS Server Solid-State Drive (SSD) This publication provides procedures for installing the SDS Server Solid-State Drive (SSD) to NCR Software Defined Store (SDS) Server (1616) . Caution: To prevent injury or product damage when handling SSDs, observe the following precautions: •...
-
Page 5: Kit Contents
SDS Server Solid-State Drive (SSD) Kit Contents Part Number Description 497-0530404 1611-K005 SDS Server SSD, Samsung PM883 960GB, AED 006-8628121 Samsung PM883 960GB - MZ7LH960HAJR-00005 497-9999638 Static Bag, 4" X 5", Self seal, Bubble 497-9999639 Static/ESD Warning Label, 1 3/4” X 2 1/2” 497-9999670 Carton - 555 Series Corrugated with Convoluted Foam 6x6x2 497-0423108... - Page 6 SDS Server Solid-State Drive (SSD) Part Number Description 497-0530406 1611-K007 SDS Server SSD, Samsung PM883 1.92TB, AED 006-8628122 Samsung PM883 1.92TB - MZ7LH1T9HMLT-00005 497-9999638 Static Bag, 4" X 5", Self seal, Bubble 497-9999639 Static/ESD Warning Label, 1 3/4” X 2 1/2” 497-9999670 Carton - 555 Series Corrugated with Convoluted Foam 6x6x2 497-0423108...
-
Page 7: Installation Procedures
SDS Server Solid-State Drive (SSD) Installation Procedures Warning: Please ensure that the Device’s power is turned OFF and the power cable is unplugged before removing the cover to replace or install the SSD. Serious damage may occur if an SSD is removed or installed while the power is ON. Even though many devices support SATA’s Hot Plugging (Hot Swapping) feature, Samsung strongly recommends to turn the power OFF before starting the installation process. - Page 8 SDS Server Solid-State Drive (SSD) 4. If an SSD is already installed in the SDS Server, remove the old SSD from the SSD Cage. For more information, refer to Removing the SSD on page 8. 5. Install the new SSD into the SSD Cage and return the cage into the chassis. For more information, refer to Installing the SSD on page 10.
- Page 9 SDS Server Solid-State Drive (SSD) Unmounting the SDS Server from the Server Rack To unmount the SDS Server from the Server Rack, do the following: • While supporting the weight of the SDS Server, remove the four (4) mounting screws that secure the Server to the Server Rack, and then lift the Server off the rack.
-
Page 10: Removing The Top Cover
SDS Server Solid-State Drive (SSD) Removing the Top Cover To remove the Top Cover, follow these steps: 1. Remove five (5) screws from the chassis (two on each side and one on the back), as shown in the image below. 2. - Page 11 SDS Server Solid-State Drive (SSD) Removing the SSD To remove the SSD, follow these steps: 1. Remove four (4) screws from the bottom that secure the SSD Cage to the chassis. 2. Remove the SSD Cage from the chassis.
- Page 12 SDS Server Solid-State Drive (SSD) 3. Do the following:. • Remove the top four (4) screws to detach the top SSD. • Remove the bottom (4) screws to detach the bottom SSD. 4. Disconnect the SATA and power cables. 5. Slide out the SDD from the SDD Cage.
- Page 13 SDS Server Solid-State Drive (SSD) Installing the SSD To install the SSD, follow these steps: 1. Slide the SSD into the SSD Cage. 2. Do the following: • Secure the top SSD to the SSD Cage using four (4) screws. •...
- Page 14 SDS Server Solid-State Drive (SSD) 4. Position the SSD Cage on the chassis and secure using four (4) screws on the bottom of the chassis. Note: If using two drives, orient the drives with the cable connections facing the motherboard.
-
Page 15: Installing The Top Cover
SDS Server Solid-State Drive (SSD) Installing the Top Cover To install the Top Cover, follow these steps: 1. Place the Top Cover on the chassis, as shown in the image below. 2. Secure the Top Cover using five (5) screws (two on each side and one on the back). - Page 16 SDS Server Solid-State Drive (SSD) Mounting the Server on the Server Rack To mount the SDS Server to the Server Rack, align its mounting holes with the through-holes of the Server Rack, and then secure the Server with four (4) mounting screws.
