Lezyne MACRO STVZO 500+ Manual

74323-A1
MANUAL - EN -
READ ENTIRE MANUAL BEFORE OPERATION to ensure proper use and care of your new Lezyne LED light. Traffic laws manda�ng
ligh�ng vary from country to country. Inform yourself about ligh�ng laws and regula�ons in the country of use.
Warnings
DO NOT LOOK DIRECTLY INTO LIGHT BEAM or shine into eyes of another.
Lezyne LED Lights have a water resistance ra�ng of IPX7 under IEC standard 60529. Submerging the device is not recommended. If
moisture does enter the casing, air out un�l completely dry.
DO NOT ATTEMPT TO REMOVE ELECTRONICS. Doing so will void warranty.
Lezyne USA Inc. does not accept any liability for injuries or other damages resul�ng from the use of this product in any circumstances.
Warranty
In U.S. and U.K., Lezyne LED Lights carry a two (2) year warranty from the original purchase date to the original owner (proof of
purchase required). Lezyne Ba�eries carry a six (6) month warranty from the original purchase date. Lezyne warran�es cover any
manufacturing defects in materials or workmanship. Issues not covered by warranty include normal wear & tear, improper
installa�on, a�emp�ng to access or modify electronics, damage or failure due to accident, misuse, abuse and/or neglect.
For all warranty issues worldwide, please contact the retailer that sold the product.
For any warranty ques�ons contact: warranty@lezyne.com
Mounting
The light must be mounted in a height between 400 mm and 1200 mm. It must be ensured that the light technical equipment
will not be covered by any parts of the bike (�re, etc...).
Between
400 mm
and
1200 mm
MACRO STVZO 500+
SUPER STVZO 600+
Operation
1. On/Off: hold bu�on two (2) seconds.
2. Mode cycle: click bu�on
MODE MEMORY: The light remains in the output se�ng it is switched OFF in.
THERMAL PROTECTION: If the opera�ng temperature of the light is too high, the light automa�cally lowers the lumen output.
„ RACE MODE":
In Race Mode, only the modes "Blast" and "Economy" are available. A short press of the "On/Off" bu�on only switches between
these two modes.
Turn on "Race Mode": With the light off, press and hold the "On/Off" bu�on for 5 seconds un�l the light comes on. Now only "Blast"
and "Economy" modes are available.
Turn off Race Mode: Repeat the above process.
A no�ce:
Switching off the light does not automa�cally switch off the "Race Mode". The "Race Mode" must first be switched off as described
above.
Run Times and Modes
MACRO STVZO 500 +
FEMTO ECONOMY
40
LUMENS LUMENS
18:00 6:00
h : min h : min
Power Pack +
Normal
USB mode
Power Pack +
Lower battery
USB mode
RACE MODE
SUPER STVZO 600 +
FEMTO ECONOMY
40
LUMENS LUMENS
25:00 11:00
h : min h : min
Power Pack +
Normal
USB mode
Power Pack +
Lower battery
USB mode
RACE MODE
Battery Indicator
An LED, located in the bu�on, displays current ba�ery status while light is ON. When light is OFF, click bu�on once to
momentarily display ba�ery status.
100%
Illuminates green
Charging
Before using your Lezyne LED Light for the first �me, fully charge the ba�ery.
To charge your light:
1. Switch light OFF
2. Remove USB-C protec�ve cover
3. Connect USB-C cable and light to powered USB-C port
4. Once charging, bu�on will flash green; if USB-C port is capable, light will use High Efficiency (HE) charging and bu�on will flash
blue.
If bu�on does not flash when plugged in, selected USB-C port may not be powered—try another USB-C port.
Light will be charged a�er 4–9 hours (3–7 with HE charging) or when bu�on illuminates solid green or blue.
5. Remove light from charger and reinstall USB-C protec�ve cover—ensure USB-C protec�ve cover is fully installed for water
resistance.
Charging Fully Charged
Flashes green Illuminates green
Charging time
Charging
Power
18W
(9V2A)
15W
High Efficiency (HE) Charging
(5V3A)
10W
(5V2A)
5W
Standard Charging
(5V1A)
More Information
For more informa�on on Lezyne products, visit:
Lezyne USA, 645 Tank Farm Rd., Unit F, San Luis Obispo, California 93401
MACRO STVZO 500+
SUPER STVZO 600+
MACRO STVZO 500+
MACRO STVZO 500+
BLAST
ENDURO
250 350 500
LUMENS LUMENS
4:00 3:00
h : min h : min
ENDURO BLAST
250 420 600
LUMENS LUMENS
7:00 4:00
h : min h : min
50%
Illuminates yellow
or red/green
USB-C Cable Not Included
Model
MACRO
STVZO 600 +
STVZO 500 +
2h:45m
4h:00m
4h:15m
4h:30m
www.lezyne.com
SUPER STVZO 600+
SUPER STVZO 600+
10%
Illuminates red
SUPER
4h:30m
5h:00m
7h:00m
9h:00m
74321-EMANUAL FOR Y17 MACRO STVZO 500+ SUPER STVZO 600+ -EN-R0A1
Charging Fully Charged
Flashes blue Illuminates blue
High Efficiency (HE) charging
