01865 767676
sales@unicol.com
www.unicol.com
GC25 / GC35
Screen Size: n/a
Guide Max. Weight: 120kg
Revised 05/01/24
*Please check model specific details before installing*
WARNING
Please carefully inspect the product before assembling. If you notice any apparent damage, call your
carrier claims agent and do not continue the installation until it has been reviewed. Please watch for pinch
points. Do not put your fingers between moveable parts. Do not tamper with or disassemble any spring
loaded parts. Before installing, make sure that the supporting surface will support five times the combined
load of the solution and the hardware. Never exceed the maximum load capacity. Please also layout all
components to ensure that you have all of the required parts before proceeding (see BOM list on following
page). Use of this product for anything other than its specified use may result in failure or personal
injury. This product is intended for indoor use only. We recommend using a qualified trades person for
installation. Use an assistant or lifting equipment to lift and position products.
For support, please call: +44 (0)1865 767676 or email: sales@unicol.com
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Unicol GC25
Summary of Contents for Unicol GC25
- Page 1 Use of this product for anything other than its specified use may result in failure or personal injury. This product is intended for indoor use only. We recommend using a qualified trades person for installation. Use an assistant or lifting equipment to lift and position products. For support, please call: +44 (0)1865 767676 or email: sales@unicol.com...
- Page 2 01865 767676 sales@unicol.com www.unicol.com TOOLS REQUIRED INSTALLERS REQUIRED 3/16th Allen Keys 17mm Spanner 19mm Spanner COMPONENTS DESCRIPTION Girder Clamp Body Girder Clamp End Plates Spare Fixings Revised 05/01/24...
- Page 3 STEP 2 STEP 1 The GC25 and GC35 will be packaged fully Hold the mount up to the girder and fit the first assembled. To start, simply unscrew the two end end plate over the edge and back onto the bolts, plates and remove, leaving the bolts and suspension securing loosely to begin with.
- Page 4 Any Questions? +44 (0)1865 767676 sales@unicol.com unicol.com/instructions...
