01865 767676
sales@unicol.com
www.unicol.com
AXC15T / AXC15P
Screen Size: 33 - 57"
Guide Max. Weight: 35kg per screen
Revised 05/01/24
*Please check model specific details before installing*
WARNING
Please carefully inspect the product before assembling. If you notice any apparent damage, call your
carrier claims agent and do not continue the installation until it has been reviewed. Please watch for pinch
points. Do not put your fingers between moveable parts. Do not tamper with or disassemble any spring
loaded parts. Before installing, make sure that the supporting surface will support five times the combined
load of the solution and the hardware. Never exceed the maximum load capacity. Please also layout all
components to ensure that you have all of the required parts before proceeding (see BOM list on following
page). Use of this product for anything other than its specified use may result in failure or personal
injury. This product is intended for indoor use only. We recommend using a qualified trades person for
installation. Use an assistant or lifting equipment to lift and position products.
For support, please call: +44 (0)1865 767676 or email: sales@unicol.com
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Unicol AXC15T
Summary of Contents for Unicol AXC15T
- Page 1 Use of this product for anything other than its specified use may result in failure or personal injury. This product is intended for indoor use only. We recommend using a qualified trades person for installation. Use an assistant or lifting equipment to lift and position products. For support, please call: +44 (0)1865 767676 or email: sales@unicol.com...
-
Page 2: Tools Required
01865 767676 sales@unicol.com www.unicol.com TOOLS REQUIRED INSTALLERS REQUIRED 4mm & 5mm Allen Keys Pozi Head Screwdriver 19mm Spanner 17mm Spanner COMPONENTS DESCRIPTION 1500mm Mast with Power Socket Axia Trolley Base Universal Mount Arms Universal Mount Backplate 7.5cm Castors (2 standard, 2 braked) - Page 3 01865 767676 sales@unicol.com www.unicol.com STEP 2 STEP 1 With mast laying flat on a table (as shown above) Once secure, stand the stand/trolley upright and pick up the base with the help of another person place on a flat, stable surface.If building the trolley and offer the base to the mast.
- Page 4 01865 767676 sales@unicol.com www.unicol.com STEP 5 STEP 6 Locate the mounting holes on the back of your Using another team member, lift the screen up and screen. Line the two mounting arms up (position gradually offer it up to the back plate. Gently tilting...
- Page 5 01865 767676 sales@unicol.com www.unicol.com STEP 9 STEP 10 [OPTIONAL] Using the 4-way socket for power and mast as a If using a shelf or locking cabinet, offer it up to the cable conduit, cable up your screen as shown above.
- Page 6 01865 767676 sales@unicol.com www.unicol.com SBT GENERAL ASSEMBLY INSTRUCTIONS The SBT fixes to the 4x 150x150mm centre holes on Connect your device to mount plate . Each mount the mast of some stands/trolleys. In some cases, this is dedicated to your device so may vary from the may include a span bar unit.
- Page 7 01865 767676 sales@unicol.com www.unicol.com VCM1 / VCMT 1. The VCM can be fitted above or below the screen. It sits between mast and mount, slotting over the top 2 bolts that attach the screen mount to the stand. Loosen these bolts, slot the VCM in and tighten bolts.
-
Page 8: Any Questions
Any Questions? +44 (0)1865 767676 sales@unicol.com unicol.com/instructions...
