A35/A35: 2100 / 2360 W (无可选项) 可选: 冷凝水蒸发器 30-110W (A35/A35 ca. 70W) 型号 DTI 8665 IC LAP DTI 8665 IC LAP RS DTI 8665 IC CM LAP DTI 8665 IC CM LAP RS 电流 * 20 A 20 A 20 A...
1 Hints on the manual This handbook contains instructions for the installation and operation of door or side-mounted, bolt-on Cooling Units provided by Pfannenberg. In this manual, safety recommendations and other information are structured as follows. If the measures described in the following are not strictly observed there is danger to life and health.
(Also refer to warranty 16 Any damage must be reported immediately to the forwarding agent Moreover, the latest edition of the "Pfannenberg After Sales Service Declaration" shall apply. •Before disposing of packing material ensure that it does not contain any loose components.
6 Safety Cooling units produced by Pfannenberg are designed for use in dissipating heat from switch cabinets (IP 55). The cooling unit is only suitable for installing on the stationary operation. Only the authorized specialist can work on the cooling system and electrical components.
12. IP55 protection class Please refer to technical data for the detailed function of the cooling unit. (See section 8) 7.2 Operating principles The compressor (1) compresses the refrigerant until high pressure is achieved. During this process temperature increases. In the condenser (2) heat is dissipated to ambient air, the coolant becoming liquid. The condenser fan (5) takes ambient air in through the condenser, and then it releases the air.In the expansion valve (3) the pressure of the coolant drops.
8.2 Spare parts Please order your spare parts only with the Pfannenberg-parts-number. Spare parts DTI 8665 Internal fan 18861100031 External fan 18861100032 Body Posture Sensor 18865500055 Compressor 18861200010 External fan capacitor 18864000000 Internal fan capacitor 18864000007 Compressor capacitor 18864000014 Filter dryer 18865000000 18865500060(主板)...
8.4 Installation for sealing Panel of cabinet Sealing Cooling unit 8.5 Airflow principle Read this manual completely and carefully before installing the unit. Prior to mounting, ensure that the clearance of the units to each other and to the wall is at least 200mm; air inlet and outlet are not obstructed on the inside of the enclosure.
A35/A35: 2100 / 2360 W (w/o options) Power consumption 30-110W (A35/A35 ca. 70W) Condensate evaporator (CM) DTI 8665 IC LAP DTI 8665 IC LAP RS DTI 8665 IC CM LAP DTI 8665 IC CM LAP RS Type 20 A 20 A...
Page 35
impede air circulation in the internal cabinet. • The power supply must be switched off when installing the cooling unit. • site of installation must be protected against contamination. If the cooling unit is mounted on an switch cabinet door, it must be confirmed that hinges can support the additional weight or that the switch cabinet will not topple over when the door is opened.
9.3 Electrical connection • The cooling unit must be connected to the mains by means of a disconnecting device with a contact gap of at least 3mm when switch off. • No temperature regulator allowed to be series-connected to the cooling unit up-stream feed. •...
Communication Connection: The unit supports standard Modbus protocol and RTU mode. The factory default communication address: "1", Bau: "9.6Kbps". RS485 allows 32 units to be connected together as a network. In order to link cooling units, following methods shall be taken: •...
generate an alarm when there is a failture during power-on self-test. ’ switched on without the front cover mounted, otherwise it will be damaged by poor heat dissipation. 11.2 Operation display The cooling unit is provided with an operation display,after the power supply is switched on, then cabinet internal temperature is shown,This indicates the unit works properly.
11.5 Human perception low noise mode When the human body sensing device senses movement of speed between 1.0 ~ 1.5 m/s near the cooling unit, internal fan goes into low noise mode. Low noise mode runs with time relay to avoid frequent on and off. Unit exits from low noise mode when no further movement is detected.
Page 40
Sign Description Lighting Remark Operation Display Self-check Self-check Available Cooling Cooling Available Heat Running Available Humidity ----- Not used Running Available Alarm Alarm Available 12.1 View Parameters In the main interface of the operation panel, press and hold the "Select" button for 3s, when the operation “...
Page 41
“ ” Operation Display Press“▼”key ”PASS” Press“Select”key ”SEE” Main interface long press“Select”key Password Interface: Default display: 000, Use the "▲" or "▼" keys to enter the password "666" , by pressing the Press“Select”key select "▲" key to enter the value, press the "▼" key to shift the value input.
Page 42
At any interface, system returns back to home page without pressing any button for 180s. For factory password recovery, please consult our Pfannenberg service team.(www.pfannenberg.com) After the factory reset is reset, please power off and restart the cabinet air conditioner. The device provides a maximum of 200 historical alarm records, and when the factory settings are restored, the historical alarm will also be cleaned up accordingly.
12.4 Remote settings The cooling unit has two RS485 serial communication connection ports, and supports standard Modbus protocol RTU mode. (See appendix II) The cooling unit can be remotely monitored and controlled. For further support you may ask our service team for technical solution.
When discarding, please consult our www.pfannenberg.com/disposal Pfannenberg service team ( 16 Trouble shooting In spite of careful maintenance, the equipment may still have a failure sometime. The real-time self-check function help diagnose the failure.
1) Check whether the external air duct is blocked 2) Check whether the fan is running normally The system pressure is too AL07 3) Check whether the condenser is dirty and blocked, and high clean the outer surface of the condenser. 4) Check the pressure sensor cable 1) If alarm AL06, cooling until stops running;...
AppendixⅠ Shown parameters (operation display): Display code hierarchy Level 1 code Level 2 code Description Level 1 code Level 2 code Description Air inlet of the temperature Air outlet of the temperature (Sta) Internal reservation, do not modify the Energy-saving temperature setting Force Mode parameters, otherwise the device will not (tP)...
Appendix Ⅱ Communication address Range Address Display Value Command Description Default Unit Data description (Decimal) code property code values Analog ℃ Air inlet of the temperature Data= Actual value*10 Analog ℃ Air outlet of the temperature Data= Actual value*10 Analog ℃...
Page 48
All the parameters in the attached table should not be changed by mistake, and failure to follow the instructions of Pfannenberg will result in the invalidation of the product warranty clause. All parameters not mentioned are reserved for Pfannenberg, and the final use and interpretation rights belong to Pinnenberg All parameters not mentioned should not be changed without authorization, otherwise the device will not work normally.
