Data
Projector

Operating Instructions

Before operating the unit, please read this manual and supplied Quick Reference Manual
thoroughly and retain it for future reference.
VPL-EX175/EX145/EX120/EX100
Not all models are available in all countries and area. Please check
with your local Sony Authorized Dealer.
© 2010 Sony Corporation
4-198-889-13 (1)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VPL-EX100 and is the answer not in the manual?

Questions and answers

Related Manuals for Sony VPL-EX100

Summary of Contents for Sony VPL-EX100

  • Page 1: Operating Instructions

    4-198-889-13 (1) Data Projector Operating Instructions Before operating the unit, please read this manual and supplied Quick Reference Manual thoroughly and retain it for future reference. VPL-EX175/EX145/EX120/EX100 Not all models are available in all countries and area. Please check with your local Sony Authorized Dealer.

  • Page 2: Table Of Contents

    Table of Contents Overview Network Location and Function of Controls ..3 Using Network Features (VPL-EX145/ EX175 only) ........23 Main unit ........3 Displaying the Control Window of Connector Panel ......4 the Projector with a Web Remote Commander and Control Browser ........23...

  • Page 3: Location And Function Of Controls

    Ventilation holes (exhaust) Caution Do not place anything near the ventilation holes as this may cause internal heat buildup. Do not place your hand near the ventilation holes and the circumference as this may cause injury. Location and Function of Controls...

  • Page 4: Connector Panel

    EX175 only) This connector outputs the projected image or Video: RGB input connector (RGB) audio. The image is output as a computer signal Audio: Audio input connector (AUDIO) input from the RGB input connector (INPUT c S VIDEO (S VIDEO IN)

  • Page 5: Remote Commander And Control Panel

    2 Press the V/v/B/b keys to move the digital zoom icon to the point on the image you wish to enlarge. 3 Press the D ZOOM + key or the D ZOOM – key repeatedly to change the enlargement ratio. The image can be enlarged up to 4 times.
  • Page 6 VOLUME +/– key Back For adjusting the volume output. FREEZE key 4 Press the V/v key to select the item Pauses a projected image. Press again to then press the ENTER key. restore the image. 5 Press the V/v key to select the setting value.

  • Page 7: Connecting The Projector

    • Insert the cable plugs firmly; Loose connections may reduce performance of picture signals or cause a malfunction. When pulling out a cable, be sure to grip it by the plug, not the cable itself. • For more information, refer also to the instruction manuals of the equipment you are connecting.

  • Page 8: Connecting A Video Equipment

    Connecting a Video equipment Connections with a VHS video deck, DVD player, or BD player are explained for each input signal. S VIDEO IN For connecting video equipment with an S-video output connector. S video cable (not supplied) S video output...

  • Page 9: Connecting An External Monitor And Audio Equipment

    Audio equipment Note Projected images and audio can be output. The image is output only as a computer signal input from the RGB input connector (INPUT A/INPUT B (INPUT B is available only for VPL-EX120/EX145/ EX175)) or a video signal input from the YP input connector (INPUT A).

  • Page 10: Projecting/Adjusting An Image

    B Projecting/Adjusting an Image Projecting an Image The size of a projected image depends on the distance between the projector and screen. Install the projector so that the projected image fits the screen size. For details on projection distances “Projection Distance” (page 38)

  • Page 11: Adjusting The Projected Image

    Notes • Be careful not to let the projector down on your fingers. • Do not push hard on the top of the projector with the adjuster extended. It may cause malfunction. Projecting an Image...
  • Page 12 Automatically adjusts Phase, Pitch and Shift of projected image while a signal is input from a computer (APA (Auto Pixel Alignment)). Press APA on the remote commander. Press again to cancel during the setting. You can also set APA in The Screen Menu (page 16).

  • Page 13: Turning Off The Power

    The message appears. Press it again according to the message. Unplug the AC power cord from the wall outlet. After step 1, the fan continues to run for a while to reduce internal heat, however, you may also unplug the AC power cord before the fan stops.

  • Page 14: Using A Menu

    B Adjustments and Settings Using a Menu Using a MENU Note The menu displays used for the explanation below may be different depending on the model you are using. value of an item to its factory preset Press the MENU key to display the value, press the RESET key during menu.

  • Page 15: The Picture Menu

    *5: When a B & W signal is input, this option is not available. *6: When an analog TV signal is input, this option may not available, depending on the color system. *7: When a progressive signal is input, this option is not available.

  • Page 16: The Screen Menu

    The lower the setting, the image farther down. Notes *1: • Note that if the projector is used for profit or for public viewing, modifying the original picture by switching to the aspect mode may constitute an infringement of the rights of authors or producers, which are legally protected.
  • Page 17 (4:3) (Full1) *2: If you select “Full2,” the image is projected to fit the projected image size, regardless *1 *2 (16:9) (Full1) of the aspect ratio of the image.

  • Page 18: The Function Menu

    On/Off: When set to “On,” the Start Up Image is displayed on the screen upon startup of the projector. Note *1: Executes APA when a computer signal is input via the RGB input connector (INPUT A/INPUT B (INPUT B is available only for VPL-EX120/EX145/EX175)). The Function Menu...

  • Page 19: The Operation Menu

    Note *1: You will not be able to use the projector if you forget your password. If you call qualified Sony personnel because you have forgotten the password, you will be asked to verify the projector’s serial number and your identity. (This process may differ in other countries/regions.) Once your identity has been confirmed, we will provide you with the password.

  • Page 20: The Connection/Power Menu

    Notes *1: The image may not be adjusted properly depending on the type of input signal. In such a case, adjust it manually to suit to the connected equipment. *2: When “Standby Mode” is set to “Low,” the network and network control function cannot be operated while the projector is in standby mode.

  • Page 21: The Installation Menu

    Notes *1: Since the Keystone adjustment is an electronic correction, the image may be deteriorated. *2: When “High Altitude Mode” is set to “On,” the speed of the fan increases, and the fan noise becomes slightly louder. The Installation Menu...

  • Page 22: The Information Menu

    The Information Menu The Information menu enables you to confirm various information on the projector, such as the total usage hours of a lamp. Items Item descriptions Model Name Displays the model name. Serial No. Displays the serial number. fH / fV (horizontal...

  • Page 23: Using Network Features (Vpl-Ex145/Ex175 Only)

    • The menu displays only English. • If the browser of your computer is set to [Use a proxy server] when you have access to the projector from your computer, click the check mark to set accessing without using a proxy server.

  • Page 24: Confirming The Information Regarding The Projector

    Setup page Set under [Password] of the Setup page. a Computer When you access the Setup page for the first You can control the projector from the time, enter “root” for user name and enter computer on the Control page.
  • Page 25 SMTP server. • You cannot use the following characters to enter the characters in the text box: “ ' ”, “ “ ”, “ \ ”, “ & ”, “ < ”, “ > ” Using Network Features (VPL-EX145/EX175 only)

  • Page 26: Indicators

    B Others Indicators The indicators allow checking the status and notify you of abnormal operation of the projector. If the projector exhibits abnormal status, address the problem in accordance with the table below. ON/STANDBY indicator Status Meaning/Remedies Lights in red The projector is in Standby mode.

  • Page 27: Messages List

    Messages List When any of the messages listed below appears on the projected image, address the problem in accordance with the table below. Message Meaning/Remedy Page High temp.! Lamp off in Check the items below. 3, 21, 1 min. • Check to see if nothing is blocking the ventilation holes.

  • Page 28: Troubleshooting

    Troubleshooting Before asking to have the projector repaired, try to diagnose the problem, following the instructions below. Symptom Remedy Page The power is not turned Check if the AC power cord is firmly connected. – When the “Panel Key Lock” is set to “On,” you cannot turn on the projector using the ?/1 key on the projector.
  • Page 29 Check that the batteries are not exhausted. – work. The fan is noisy. The sound from the fan is often greater than normal to cool the 18, 21 lamp, etc. in the following cases. • “Lamp Mode” is set to “High.”...

  • Page 30: Replacing The Lamp

    Replacing the Lamp Replace the lamp with a new one if a message displayed on the projected image or the LAMP/ COVER indicator notifies you to replace the lamp (pages 26, 27). Use an LMP-E211 projector lamp (not supplied) for replacement.
  • Page 31 Insert the new lamp all the way in until Caution it is securely in place. Tighten the Disposal of the used lamp 2 screws. For the customers in the USA Lamp in this product contains mercury. Disposal of these materials may be regulated due to environmental considerations.

  • Page 32: Cleaning The Air Filter

    Cleaning the Air Filter When a message appears on the projected image, clean the air filter (page 27). If the dust cannot be removed from the air filter even after cleaning, replace the air filter with a new one. For details on a new air filter, consult with qualified Sony personnel.

  • Page 33: Specifications

    VPL-EX175: 3600 lm (when “Lamp Mode” is set to “High”) Speaker VPL-EX100/EX120: 1W × 1 (monaural) VPL-EX145/EX175: 10W × 1 (monaural) Applicable Horizontal: 14 kHz to 93 kHz, Vertical: 47 Hz to 93 Hz scanning frequency Resolution When a computer Maximum display resolution: 1600 × 1200 pixels (resize) signal is input Panel display resolution: 1024 ×...
  • Page 34 5 kohms Others connector RS-232C connector: D-Sub 9 pin female LAN connector (VPL-EX145/EX175 only): RJ45, 10BASE-T/100BASE-TX Operating 0 °C to 40 °C (32 °F to 104 °F)/35% to 85% (no temperature/ condensation) Operating humidity Storage –20 °C to +60 °C (–4 °F to +140 °F)/ 10% to 90%...
  • Page 35 *1: For details, refer to “Acceptable Input Signals” on page 37. *2: Information on accessories in this manual is current as of August 2010. *3: Not all optional accessories are available in all countries and area. Please check with your local Sony Authorized Dealer.
  • Page 36 Pin assignment RGB input connector (Mini D-sub 15-pin, female) Video input Power supply (red) R input for DDC Video input (green) G Video input (blue) B DDC/SDA RESERVE Horizontal sync signal GND (R) Vertical sync signal GND (G) DDC/SCL GND (B)
  • Page 37 1152 × 864 64.0/70 Notes 67.5/75 *1: With INPUT A only 77.5/85 • When a signal other than the signals listed in 1152 × 900 61.8/66 table is input, the picture may not be 1280 × 960 60.0/60 displayed properly.

  • Page 38: Projection Distance

    The projection distance is the distance between the front of the lens and the surface of the projected image. Height H is the height from the bottom of the projected image (top for ceiling mount) to A (determined by drawing a perpendicular line from lens center to projected image surface).
  • Page 39 0.24 (9) 0.46 (18) Projection distance formula D: Projected image size (Diagonal) H: Distance between the bottom edge of the image and the center of the lens Expression#1 (Projection Distance L) Unit: m (inches) Minimum Projection Distance L Maximum Projection Distance L L=0.028462 ×...
  • Page 40 H=0.00017 × D – 0.00046 (H= – 0.01817 × D + 0.00941) (H=0.00663 × D – 0.01802) In the case of ceiling mounting, check with your dealer regarding the use of a mount kit that is warranted for use with this product. Projection Distance...

  • Page 41: Dimensions

    Dimensions Front 313.4 (12 79.7 (3 Unit: mm (inches) Side 269 (10 114.1 (4 Unit: mm (inches) Dimensions...
  • Page 42 Side (The bottom is parallel to the ceiling.) 13.4 ( Center of the lens 76.7 (3 Unit: mm (inches) Bottom 24.4 ( 27.3 (1 40.2 Center of the lens 77 (3 40.2 131.8 8.2 ( 24.4 ( 18.1 ( 22.7 ( 79.3 (3...

  • Page 43: Index

    Connecting an external monitor and audio LAN ............4 equipment ..........9 Language ..........19 Connecting a Video equipment ....8 Location and function of controls ..... 3 Connection/Power menu ......20 Connector panel ........3, 4 Contrast ...........15 Main unit ........... 3 Control panel ..........5 Messages list ...........
  • Page 44 Primary DNS ........... 20 About Trademarks Projecting an image ......... 10 • Adobe Acrobat is a trademark of Adobe Projection distance ........38 Systems Incorporated. • Kensington is a registered trademark of Kensington Technology Group. Remote commander ........5 • Internet Explore is registered trademarks Remote control detector ......
  • Page 45 Sony Corporation...
