Serial No.: H-V073-E-04
Compact ball valve Type 27
Manual type
User's Manual
Thank you for choosing our product.
This instruction manual contains important information for safe use of our
product, so please be sure to read it before handling the product.
After reading this manual, please be sure to keep it in a place where the
user can see it at any time.
[User's Manual] Compact ball valve type 27
- 1 -
Advertisement
Table of Contents
Related Manuals for AsahiAV V7BLB Series
Summary of Contents for AsahiAV V7BLB Series
- Page 1 Serial No.: H-V073-E-04 Compact ball valve Type 27 Manual type User’s Manual Thank you for choosing our product. This instruction manual contains important information for safe use of our product, so please be sure to read it before handling the product. After reading this manual, please be sure to keep it in a place where the user can see it at any time.
- Page 2 Serial No.: H-V073-E-04 -SAFETY PRECAUTIONS- This instruction manual is written on the assumption that the person who handles our products has a basic knowledge of our products, electrical equipment, machinery, control, etc., and it contains technical terms depending on the handling contents. Please read this manual carefully and fully understand the contents and observe the safety precautions for proper use.
-
Page 3: Table Of Contents
Serial No.: H-V073-E-04 Table of contents 1. Our product warranty coverage ··························································································· 4 Applicable to ..................................4 Warranty Period ................................. 4 Guaranteed range ................................4 Disclaimer ................................... 4 2. Safety Instructions ················································································································ 5 Unpacking, Transportation and Storage ........................5 Product Handling ................................6 3. -
Page 4: Our Product Warranty Coverage
Serial No.: H-V073-E-04 1. Our product warranty coverage Unless otherwise stated in the Contract or Specifications, etc., the warranty for the piping material products (hereinafter referred to as "applicable products") such as valves manufactured or sold by us is as follows. Applicable to This warranty applies only when the product is used in Japan. -
Page 5: Safety Instructions
Serial No.: H-V073-E-04 2. Safety Instructions Unpacking, Transportation and Storage The valve can be damaged, or leak. ▶ Do not subject the product to impact by throwing, dropping or hitting. Prohibited ▶ Do not scratch or pierce the product with a sharp object such as a knife or hand hook. ▶... -
Page 6: Product Handling
Serial No.: H-V073-E-04 Product Handling Serious injury can result. ▶ If positive pressure gas is used for our resin piping material, a dangerous condition may Forcing occur due to the repulsive force peculiar to compressible fluids even if the pressure is the same as the water pressure. -
Page 7: Name Of Parts
Serial No.: H-V073-E-04 3. Name of parts Handle End connector Body 4. Product Specifications Model number table ..............................Body Seal Actuation Valve type Operation type Connection Standard Size High purity series material material ＊ ＊ ＊ ＊ ＊＊＊ ＊ V Automatic 7B Type 27 LV Lever type U U-PVC... -
Page 8: Mounting Method
Serial No.: H-V073-E-04 5. Mounting method Threaded end Serious injury can result. ▶ When hanging or slinging a valve, pay sufficient attention to safety, and do not enter Prohibited under the load. Serious injury can result. ▶ Be sure to perform safety inspections of the machine tool and power tool beforehand. Forcing ▶... -
Page 9: Socket End (Adhesive)
▶ After piping, open both ends of the pipe and use a blower (low-pressure type) to ventilate to remove the solvent vapor. ▶ Use "ASAHIAV Cement" depending on the material. ▶ Perform the water flow test after 24 hours or more have elapsed after completion of bonding. - Page 10 Serial No.: H-V073-E-04 ASAHIAV glue Waste cloth Preparations [Procedure] 1) Wipe off the insertion part of the pipe and the socket part of the body cap with a waste cloth. 2) Refer to "Table 5-1 Adhesive Consumption (Reference)" and apply adhesive evenly in the order of the socket part of the body and body cap and the insertion part of the pipe.
-
Page 11: Operation Method
▶ After piping, open both ends of the pipe and use a blower (low-pressure type) to ventilate to remove the solvent vapor. ▶ Use "ASAHIAV Cement" depending on the material. ▶ Perform the water flow test after 24 hours or more have elapsed after completion of bonding. -
Page 12: Inspection Item
Serial No.: H-V073-E-04 7. Inspection item Fluid may leak from the valve. Forcing ▶ Maintenance should be performed every 3 to 6 months as a guide in order to keep the watch in normal condition and use it for a long time. Pay particular attention to temperature changes and aging during long-term storage or shutdown or use. -
Page 13: Periodic Inspection
Serial No.: H-V073-E-04 Periodic inspection ●Guideline for the inspection cycle: 3 months Inspection Guideline of Check point Remedy for malfunctions items and judgment methods Vibration No difference Valve Recheck the operating conditions and remove the source (palpation) from other parts of vibration. -
Page 14: Cause Of Malfunction And Remedy
Serial No.: H-V073-E-04 8. Cause of malfunction and remedy This valve cannot be disassembled ▶ Parts of this valve cannot be replaced. Replace the entire valve when a problem occurs. Forcing Failure phenomenon Possible cause Measures and measures Handle does not turn The valve is already fully Rotate the handle in the opposite direction. -
Page 15: Disposal Method Of Residual Materials And Waste Materials
Serial No.: H-V073-E-04 Failure phenomenon Possible cause Measures and measures Fluid leaks from valve O-ring is scratched, worn, Stop using the product immediately, remove the (external leak) melted, or altered valve from the piping, and replace the valve. (Ref: 5. Mounting method) Scratches or wear are found Stop using the product immediately, remove the on the sliding or fixing... -
Page 16: Inquiries
Serial No.: H-V073-E-04 Inquiries Contact the nearest dealer, our sales office, or our web website for inquiries about this product. [User’s Manual] Compact ball valve Type 27 Manual type https://www.asahi-yukizai.co.jp/en Please note that the content of this manual is subject to change without notice. February 2024 [User’s Manual] Compact ball valve type 27 - 16 -...
