Introduction

For installation instructions, pinouts, safety considerations,
and connection configurations, please reference the Safety
and Installation Manual for IS-Max and IS-Pro Intrinsically
Safe Devices found at alicat.com/manuals.
Depending on the model, Alicat devices have a variety of
features:
• 1000 readings per second guarantees
high resolution data.
• High-accuracy performance for all your flow.
Use the mass flow devices with any of the 98+
gases included with Gas Select™
• Control pressure while monitoring flow rate.
Set the closed loop control algorithm to pressure
control on your flow device
• Control either gas or liquid with
your pressure controller.
• Monitor live pressure and temperature in
mass flow or liquid processes
• Monitor humidity within the process using an optional
humidity sensor that measures relative humidity,
the dew point, and the percent of water vapor.
• Backlit display with adjustable contrast is easy to
read even in direct sunlight. In dimly lit areas, press
the logo to turn on the backlight
• Change your STP to match any standard temperature
and pressure reference for your mass flow
• Log data to your PC with a serial data
connection to control the device and capture
data for logging and analysis
This manual covers the IS-Max and IS-Pro intrinsically safe
devices. Please refer to the table of contents on the previous
page to locate specific functions regarding your device.
For further support or questions regarding the use or
operation of your device, please contact Alicat using the
information on page 2.
If you have an idea for a new process or a challenging appli-
cation, Alicat may be able to assist with one of our various
solutions or a custom solution specifically for your needs.
Introduction • Aug, 2023 • Operation Manual for IS-Max and IS-Pro Intrinsically Safe Devices • Rev 0 Draft
