Wedgetail Rails and Platform Fitting Instruction
To suit Ford F-Series 250/350/450 Dual Cab 2017– On
Congratulations on the purchase of your Australian made Wedgetail Roof Rack product.
Please read and follow the instructions carefully to ensure correct fitment.
Contact us if any parts appear missing, incorrect, or damaged.
ITEM
COMPONENT
Wildtrak 2022 Wedgetail Left Rails
1
Wildtrak 2022 Wedgetail Right Rails
2
Wedgetail Pre-assemble Platform
3
Wedgetail Wind Deflector & kits
4
M10 Unistrut
5
WT-FFS17DC-1414_Fitting_Rev1 Updated
Updated: 30 Jun 2023
•
Allen key (6 mm)
QTY
1
1
1
1
6
Tools Required:
•
Spanner (8mm & 17mm)
KIT CONTENTS
ITEM
6
7
8
9
COPYRIGHT TRADESMAN ROOF RACKS |WEDGETAILRACK.COM.AU
WT-FFS17DC-1414
COMPONENT
M10 X 20 Stainless Hex Bolt
M10 Dacro Sems Dome Head
10mm Nyloc Nut
FFS Lug
QTY
6
6
6
6
