Riverside Intrigue 39375 Assembly Instructions

email: info@riverside-furniture.com
Warning :
- Be sure to check all packing material carefully for small parts, which may have come loose inside the carton during shipment.
- To prevent possible scratches and damage, this furniture MUST BE ASSEMBLED BY TWO PEOPLE on a soft surface such as a
blanket or carpet.
Queen Panel Headboard - 39373
H-A
Allen Head Bolt
Ø5/16''-18 x 1-3/4"
10 pcs.
H-E
Queen Panel Footboard - 39375
F-A
Bed Rails - 39372
2 pcs.
R-A
5/0 Queen Bed
39373 -- 4/6-5/0 Panel Headboard
39375 -- 5/0 Metal Panel Footboard
39372 -- 5/0-6/6 Bed Rails
Assembly Instructions
Hardware and Parts packed with the Headboard
Headboard Post Left
1 pc.
H-B
Flat Washer
Spring Washer
Ø5/16'' x Ø19mm
Ø5/16''
10 pcs.
H-F H-G
Hardware and Parts packed with the Footboard
Slats 60-7/8"
1 pc.
F-B
Hardware and Parts packed with the Bed Rails
Spring Washer
Curved Washer
Ø5/16''
8 pcs.
R-B
R-C
Intrigue
Bedroom
Headboard Post Right
H-C
1 pc.
Allen key 4mm
10 pcs.
H-H 1 pc.
Support leg
1-1/4" x 1-1/4" x 6-1/4"
5 pcs.
F-C
Nut
Ø5/16''
Ø5/16" x 12mm
8 pcs.
R-D
Made in Viet Nam
Queen Panel Bed
Headboard Stretcher
1 pc.
H-D
Screw Ø4 x 1 - 3/16"
5 pcs.
F-D
All - Thread Bolt
Ø5/16''-18 x 3-1/8"
8 pcs. 8 pcs.
R-E
Page 1 of 5
1 pc.
10 pcs.
Open Wrench 12 mm
1 pc.
R-F
