Quick Installation Guide
* European version is used for demonstration in this guide.
* Images may differ from actual products.
Plug and Play
e
r l i n
w e
P o
N
L A
N
W A
Router
1
Plug the adapter into a power outlet
and connect it to the router's LAN
Adapter
port via an Ethernet cable.
TL-PA7017
2
Plug the extender into a power outlet on the same electrical circuit.
Wait until the extender's Powerline LED
Note: If the LED is off, please refer to FAQ > Q2.
3
Connect your devices to the internet using the default SSID (network
name) and password on the label at the top of the extender.
Extender
TL-WPA7517
On
Attention
1. Use the product only in the upright direction.
2. Plug powerline devices into wall outlets instead of power strips.
Note: Using power strip will affect network performance or even cause connection drops.
Wall Outlet
turns on.
SSID:TP-Link_XXXX
SSID:TP-Link_XXXX_5G
Wireless Password:XXXXXXXX
Tip:
Want to unify or personalize your network? See the back
page for instructions.
Power Strip
Advertisement
Related Manuals for TP-Link L-WPA7517
Summary of Contents for TP-Link L-WPA7517
- Page 1 Quick Installation Guide Plug the extender into a power outlet on the same electrical circuit. Wait until the extender’s Powerline LED turns on. Note: If the LED is off, please refer to FAQ > Q2. * European version is used for demonstration in this guide. * Images may differ from actual products.
- Page 2 The powerline adapter/extender is not connected to any powerline network. A3. If the problem persists, contact our Technical Support. TP-Link hereby declares that the device is in compliance with the essential requirements and other relevant Ethernet On/Off The Ethernet port is connected or not connected.
