INSTALLATION INSTRUCTIONS
CARE AND MAINTENANCE
0328 TOWNSEND
Thank you for selecting American Standard - the benchmark of fine quality for over 100 years. To ensure this
product is installed properly, please read these instructions carefully before you begin. (Certain installations may
require professional help.) Also be sure your installation conforms to local codes.
CAUTION: PRODUCT IS FRAGILE. TO AVOID BREAKAGE AND POSSIBLE INJURY HANDLE WITH CARE!
!
NOTE: Pictures may not exactly define contour of china and components.
OBSERVE LOCAL PLUMBING AND BUILDING CODES
Recommended Tools & Materials
Putty Knife
Channel Lock Pliers
Level
FINISHED
WALL
2-11/16"
(67mm)
®
PEDESTAL SINK
Adjustable Wrench
Regular Screwdriver
Phillips Screwdriver
Tape Measure
FAUCET MOUNTING HOLES:
SINGLE HOLE, 4"(102mm) OR 8"(203mm)
8-1/2"
(215mm)
29-15/16"
(760mm)
In the United States:
American Standard Brands
1 Centennial Ave.
Piscataway, New Jersey 08855
Attention: Director of Customer Care
For residents of the United States, warranty
information may also be obtained by calling
the following toll free number: (800) 442-1902
www.americanstandard.com
Product names listed herein are trademarks of AS America, Inc.
© AS America, Inc. 2020
Hacksaw
Plumbers' Putty or
Caulking
Tubing Cutter
2X
HOLES FOR
ANCHOR BOLTS
2"
(50mm)
19-1/2"
(495mm)
*22-3/4"
(578mm)
FINISHED
In Canada:
AS Canada, ULC
5900 Avebury Rd.
Mississauga, Ontario
Canada L5R 3M3
Toll Free: (800) 387-0369
www.americanstandard.ca
Pipe Wrench
Basin Wrench
Drill
Saber Saw
8-3/8"
(213mm)
8"
(203mm)
1-1/4"
O.D. WASTE
*20-1/2"
(521mm)
8"
(202mm)
FLOOR
American Standard B&K Mexico
S. de R.L. de C.V.
Via Morelos #330
Col. Santa Clara
Ecatepec 55540 Edo. Mexico
Toll Free: 01-800-839-1200
www.americanstandard.com.mx
73023 07-10 0 Re v. A (1 0 / 2 0 )
7/8"
(22mm)
SUPPLIES
AS REQ'D
1-1/4" O.D.
TAIL PIECE
35-1/4"
(896mm)
In Mexico:
