English Safety Text Plug and Fuse Information Care and Cleaning Part List To Use Your Food Processor - Presets 8-13 Usage Diagrams and Usage Instructions 8-11 Usage Chart Recipes Custom Preset 14-15 To Use Your Food Processor - Knife Blade, Dough Tool and Dual Whisk 16-19 Usage Diagrams and Usage Instructions...
Page 4
Read these instructions carefully and retain for future reference. Remove all packaging, labels and protective film. If the plug or cord is damaged it must, for safety reasons, be replaced by Kenwood or an authorised Kenwood repairer in order to avoid a hazard.
For non-rewireable Plug Type G the fuse cover MUST be refitted when replacing the fuse. If the fuse cover is lost then the plug must not be used until a replacement can be obtained. The correct fuse cover is identified by colour and a replacement may be obtained from your Kenwood Authorised Repairer (see Service). Plug Type G...
Care and Cleaning Stop the unit and unplug prior to cleaning. Push any excess cord into the storage area at the back of the power unit. Wipe the power unit and whisk drive head with a damp cloth (do not use abrasive materials), then dry. Ensure that the interlock area is clear of food debris.
Page 8
* Kui on kaasas) * If supplied * Si se incluye * Ürünle birlikte * Εάν παρέχεται gelmişse * Jei pridedamas) * Indien geleverd * Hvis en sådan * Если входит в * Ja iekļautas medfølger * Pokud je součástí комплект...
Page 9
Processor - Express Prep Pushers Feed tube Bowl Detachable drive shaft Power unit Safety interlocks Cord storage (at back) Preset control Zero button Kg/lb button Pulse control Speed control Custom pre-set control Display screen Standard Attachments Knife blade Dough tool 4mm slicing/grating disc Plastic blendedr Lid with drip feed...
Page 10
To Use Your Presets Usage Diagrams & Usage Instructions...
Page 11
IMPORTANT Always fit the bowl and attachment onto the processor before adding ingredients. Do not use the lid to operate the processor. The processor will not operate if the bowl or lid are not fitted correctly into the interlock. Check that the feed tube and bowl handle are situated to the right front hand corner.
Page 13
IMPORTANT Do not use the lid to operate the blender attachment. The processor will not operate if the blender and blender lid are not correctly fitted into the interlocks. Always stop the unit and unplug before removing the lid. Your blender is not suitable for crushing or grinding coffee beans, or converting granulated sugar to caster sugar. When adding almond essence or flavouring to mixtures avoid contact with the plastic as this may result in permanent marking.
Page 14
1–2 600 g 400 g 400 g 1–2 3–5 cm 400 g 1–3 3–5 cm 350 g 1–3 1,5 kg 1–2 600 g 1–2 1,5 L 1–2 4-8˚C 250 g 500 g (210 g – 220 g) 20x40x35 cm 4-8˚C 1–2...
Recipes Cinnamon Buns Dough: 300g Whole Milk (room temperature) 7g Dried Yeast 50g Unsalted Butter 1 Egg 450g Plain Flour 60g Caster Sugar ¼ Tsp Salt Fit the knife blade and add the milk and yeast to the food processor bowl and leave for 5 minutes. Add the remaining dough ingredients to the bowl.
Custom Preset Usage Diagrams and Usage Instructions >3 secs...
Page 17
Note: Do not run the Food Processor or Blender empty. There is a maximum time you are able to record in the custom mode, When the maximum time has been reached, the preset will automatically save. To cancel recording: Press any of the preset buttons or the scales ‘zero’ or ‘kg/lb’ button. Alternatively, cut power to the product.
To Use Your Food Processor - Knife Blade, Dough Tool and Dual Whisk Usage Diagrams & Usage Instructions...
Page 19
IMPORTANT Always fit the bowl and attachment onto the processor before adding ingredients. Do not use the lid to operate the processor. The processor will not operate if the bowl or lid are not fitted correctly into the interlock. Check the feed tube and bowl handle are situated to the right hand corner.
Page 20
(secs) 600 g High + Pulse 10–30 2 cm 1.5 kg Low–High 10–20 250 g Pulse 5–10 30–50 g High 20–30 High 340 g 170 g 85 ml High + Pulse 10–20 High 60–120 360 g High 600 g 400 g x5 (150 g) High 90–150...
Recipes All In One Sponge Cake 362g Plain Flour 13g Baking Powder 375g Caster Sugar 375g Unsalted Butter (Room Temperature) 375g Eggs Method: Fit the knife blade and add the ingredients to the food processor bowl in the order listed above. Combine the ingredients using the mix preset.
Page 22
IMPORTANT Do not use the small pusher without the larger pusher fitted, otherwise you may damage the bottom of the pusher. Never put your fingers in the feed tube. Fit the drive shaft and bowl onto the power unit. Holding by the centre grip, place the disc onto the drive shaft with the appropriate side uppermost. Fit the lid.
To Use Your Food Processor - Express Dice Attachment Usage Diagrams and Instructions...
Page 24
IMPORTANT The dicing disc is designed only to be used with the dicing attachment. The dicing pusher should only be used with the dicing grid. Using it without the dicing grid fitted will result in damage to the bottom of the pusher. Foods such as cheese, ham and chorizo will clog in the grid so are not recommended for use with this attachment.
To Use Your Food Processor - Express Serve Usage Diagrams and Instructions...
Page 26
IMPORTANT The express serve will not operate unless the small drive shaft has been fitted to the main drive shaft. Do not apply excessive force when using the attachment. If food does not exit the food outlet, switch off and check that food is not clogging under the disc and the slinger plate is fitted.
To Use Your Food Processor - Citrus Juicer Usage Diagrams and Instructions IMPORTANT The citrus juicer will not operate if the sieve is not locked correctly. Fit the drive shaft and bowl onto the power unit. Fit the sieve into the bowl - ensuring the sieve handle is locked into position directly over the bowl handle. Place the cone over the drive shaft turning until it drops all the way down.
To Use Your Food Processor - Glass Mill Usage Diagrams and Instructions Put the ingredients into the jar. Fit the sealing ring into the blade assembly. Turn the blade assembly upside down. Lower it into the jar, blades down. Screw the blade assembly onto the jar. Refer to the graphics on the underside of the blade assembly as follows: - Unlocked position - Locked position Place the mill onto the power unit and turn clockwise to lock in position.
Recipe Prune Marinade 225 g Clear Runny Honey 20 g small soft prunes 30 ml cold water Place all ingredients into the mill. Refrigerate overnight. Fit the mill to the power unit. Plug in, select and hold pulse speed and process for 4 seconds. Use as required.
Usage Chart (secs) 50 g High 10–30 50 g High To Use Your Food Processor - Grinding Mill Usage Diagrams and Instructions IMPORTANT Do not process dried turmeric root in the mill as it is too hard and may damage the blades. Place your ingredients into the blade assembly.
Page 31
Hints and Tips For optimum performance when processing spices do not process more than 50g at a time. Whole spices retain their flavour for a much longer time than ground spices so it is best to grind a small quantity fresh at a time to retain the flavour.
IMPORTANT Do not blend frozen ingredients without liquid. Leaking will occur if the sealing ring is damaged or incorrectly fitted. Add ingredients to the bottle up to the 400ml level mark. Fit the sealing ring to the blade unit, ensuring the seal is located correctly in the grooved area. Hold the underside of the blade unit and lower it onto the bottle, blades down.
To Use Your Food Processor - Plastic Blender Usage Diagrams and Instructions IMPORTANT The appliance will not operate if the blender is incorrectly fitted to the interlock. The processing of spices is not recommended as they may damage the plastic parts. Put your ingredients into the goblet.
Usage Chart (secs) 1.5 L High 30– 60 4-8˚C High 15–30 High 45–60 250 g 500 g Pulse (125 g) Recipes Mayonnaise 4 Egg Yolks 32g Dijon Mustard 350ml Oil Method Add the egg yolks and mustard to the blender. Blend on high speed for 10 seconds.
IMPORTANT Your juicer will not operate if the bowl or lid are not fitted correctly into the interlock. If the juicer starts to vibrate, switch off and empty the pulp from the drum. The juicer vibrates if the pulp becomes unevenly distributed.
Weighing Function Usage Diagrams and Instructions IMPORTANT Your food processor is fitted with a built in weighing function to allow ingredients to be weighed straight into the bowl or blender goblet. The Maximum weighing capacity is 3kg. The weight of any additional ingredients added down the feed tube whilst the processor is running will not be shown on the display screen.
Weighing Tray A removable weighing tray is supplied for weighing ingredients without the bowl or blender. To use, place the tray on top of the power unit and turn clockwise to secure. Then follow steps 2 to 4 under ‘To Use The Weighing Function’.
(in or out of guarantee) call Kenwood customer care on 0345 222 0458. Have your model number (e.g. TYPE: FDM73) and date code (5 digit code e.g. 23T04) ready. They are on the underside of the power unit.
Troubleshooting Guide Problem Cause Solution The processor will not No Power. Check processor is plugged in. operate. Bowl not fitted to power unit correctly. Check bowl is located correctly and the handle is situated towards the right front hand corner. Bowl lid not locked on correctly.
Page 63
High + Pulse – + ) سرعة عالية ( الوضع النبضي 2 cm Low–High – – Pulse – High – – High High + Pulse + ) سرعة عالية – ( الوضع النبضي High – High High – Med–High – –...
