3-INCH JUMBO LED
A L A R M CLO CK
MODEL: 30402
DC: 040924
For more information and support visit: bit.ly/30401_alarm or bit.ly/30402_alarm
POW E R U P
1. Insert the 120 volt power cord into an outlet.
Optional: Insert 1 "9V" battery (sold separately) for backup.
2. The Time Display will flash 12:00, an indication to set the time.
T I M E S E T T I N G
1. Move the TIME/ALARM/RUN Set Switch to the TIME position.
2. Press HOUR button to set your hour. Note: The PM Indicator
will appear when you advance to PM time.
3. Press MINUTE button to set your minutes.
4. When the correct time is shown on the display, move the
TIME/ALARM/RUN Set Switch to the RUN position.
A L A R M T IM E S E T T I N G & O P E R AT IO N
1. Move the TIME/ALARM/RUN Set Switch to the ALARM position.
2. Press HOUR button to set your alarm hour. Note: The PM
Indicator will appear when you advance to PM time.
3. Press MINUTE button to set your alarm minutes.
4. When the correct time is shown on the display, move the
TIME/ALARM/RUN Set Switch to the RUN position.
5. Slide the Alarm HI/LO/OFF Switch to LO position for normal
alarm volume, and to its HI position for a louder alarm volume.
Note: The Alarm Indicator will appear when the alarm is on.
6. To turn off a sounding alarm, move the Alarm HI/LO/OFF Switch
to the OFF position.
S N OOZE
When alarm sounds, press the SNOOZE button to silence alarm for
8 minutes. Snooze function can be repeated many times if desired.
Page 2
D I SP LAY D I M M E R
Move the Dimmer Switch to its LO position for normal display
brightness, and to its HI position for a brighter display.
BAT T E RY B AC K UP
• Insert 1 "9V" battery (sold separately) into the Battery
Compartment on the bottom of the clock. This will keep your
time and alarm settings saved until power is restored.
• The LED display will not light up, but the alarm will still sound at
the preset alarm time.
Note: If there is no battery installed and the power is interrupted,
the display will flash 12:00 and the time and/or alarm will need to
be set again.
STAY I N TO U C H
Ask questions, watch set up videos, and provide feedback on our social media
outlets. Follow La Crosse Technology on Youtube, Facebook, Instagram, & X
(Twitter).
P OWE R R E Q UI R E M E N TS & D I M E N S I O N S
Power: 120V Power Cord
Battery Backup: "9V" battery (sold separately)
Dimensions: 9.00" L x 2.25" W x 4.75" H
22.86 cm L x 5.72 cm W x 12.07 cm H
Page 3
Advertisement
Related Manuals for Equity 30402
Summary of Contents for Equity 30402
- Page 1 When alarm sounds, press the SNOOZE button to silence alarm for Dimensions: 9.00" L x 2.25" W x 4.75" H MODEL: 30402 8 minutes. Snooze function can be repeated many times if desired. 22.86 cm L x 5.72 cm W x 12.07 cm H...
- Page 2 5. Heat: The appliance should be situated away from heat sources such as radiators, heat During this period such defects will be repaired, or the product will be replaced at Equity’s device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable registers, stoves, or other appliances (including amplifiers) that produce heat.
Need help?
Do you have a question about the 30402 and is the answer not in the manual?
Questions and answers
In changing the time, I **** able to change the hour, but the minute button is not working. Nothing happens when I press the minute button.
If the minute button on the Equity 30402 clock is not working when changing the time, try the following steps:
1. Check the Time Setting Mode – Ensure the TIME/ALARM/RUN Set Switch is in the TIME position before pressing the MINUTE button.
2. Power Cycle the Clock – Unplug the 120V power cord, remove the backup battery (if installed), wait a few minutes, then plug it back in and try again.
3. Inspect for Obstructions – Make sure there is no dirt or debris blocking the button.
4. Press Firmly – Try pressing the button firmly but not forcefully in case it is stuck.
5. Replace the Battery – If using a backup battery, replace it with a new 9V battery to ensure proper functionality.
6. Check for Physical Damage – If the button appears physically damaged, it may require repair or replacement.
7. Contact Support – If none of the above steps work, the clock may need service under the warranty.
If the issue persists, professional service may be required.
This answer is automatically generated
set time advances to incorrect time
