Floating Shelf Instruction Manual
V1.0(C)
OR
Model: AMFS02/ AMFS03/ AMFS03B1/ AMFS03W
Thank you for choosing this AMADA product! At AMADA we strive to
provide you with the best quality products and services in the industry.
Should you have any issues, please don't hesitate to contact us at
support@amadahome.com
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Amada Homefurnishing AMFS02
Summary of Contents for Amada Homefurnishing AMFS02
- Page 1 Floating Shelf Instruction Manual V1.0(C) Model: AMFS02/ AMFS03/ AMFS03B1/ AMFS03W Thank you for choosing this AMADA product! At AMADA we strive to provide you with the best quality products and services in the industry. Should you have any issues, please don't hesitate to contact us at...
-
Page 2: Important Safety Information
IMPORTANT SAFETY INFORMATION • Check package contents against supplied parts and hardware list to assure that all components were received undamaged. Do not use damaged or defective parts. lf you require replacement parts, please contact amada customer service at support@amadahome.com. •... - Page 3 NOTE: • For drywall mounting, use wall anchors [C]. • For wood stud mounting, wall anchors [C] and [D] are not necessary. • For solid concrete, and concrete block walls, please use wall anchors [D] Secure the Metal Frames [02] to Floaing Shelf [01] Using Step 1 Four Short Screws [03] Option A:...
- Page 4 Option B: [Not Included]...
- Page 5 Step 2 Secure Metal Frame with Floating Shelf to Wall Before installation, please identify your wall type. For wood stud installation, follow the step 2A. For drywall installation, follow the step 2B. For solid concrete and concrete block walls installation, follow the step 2C Step 2A For Wood Stud Maximum inatallation width for the floating...
- Page 6 2 in (50mm) WARNING: For wood stud mounting, [Not Included] ø5/64 in (ø2mm) wall anchors [C] and [D] are not necessary. For Long Lag Screw Option A [Optional] Note: The floating shelf will be easier to falling off for pulling tension if you install the floating shelf up side down Option B...
- Page 7 Step 2B For Drywall Level (Not lncluded) Position the metal frame with floating shelf at your desired height and make sure the metal frame with shelf is level and flush to the wall. Mark the holes for the wall anchors [C]. [Not Included] Press and screw the wall anchors [C] into the drywall using a screwdriver(not Included) and turn clockwise, making sure that wall anchors [C] are flush with the wall.
- Page 8 Option B Note: The floating shelf will be easier to falling off for pulling tension if you install the floating shelf up side down Insert short lag screws [B] into wall anchors [C], tighten short lag screws [B] until the they are pulled firmly against the metal frames.
- Page 9 For Short Lag Screw 1 3/8 in (35mm) ø15/64 in (ø6mm) Drill 4 pilot holes using a 15/64 in (6mm) diameter drill bit. Make sure the depth is not less than 1.4 in (35mm). Never drill into the mortar between blocks. Use the hammer to knock wall anchors [D] into the wall.
- Page 10 Option A [Not Included] Note: The floating shelf will be easier to falling off for pulling tension if you install the floating shelf up side down Option B [Not Included] Note: The floating shelf will be easier to falling off for pulling tension if you install the floating shelf up side down Install the metal frame with floating shelf [01] using short lag screws [B] and wall...
- Page 12 Thank you again choosing this AMADA product! All of us at AMADA do appreciate your product purchase. We hope that you are as happy with your product as we are designing and manufacturing it for you. We strive to provide you with the best quality products and services in the industry. Should you have any issues, please don't hesitate to contact us at support@amadahome.com...
