T:SLIM X2 INSULIN PUMP
TruSteel Infusion Set
1
Open packaging and remove
the protective cap from the
connector needle.
⚑ Note: Clean the insertion area
with an alcohol wipe or other
recommended skin preparation.
5
When filling the tubing, hold
the steel needle pointing
down. Make sure there is no
air in the tubing. Stop after
three drops of insulin have
appeared from the needle.
9
Insert the needle and release
the pinched skin.
2
Hold the connector needle at
the point where it connects
with the tubing and insert it
into the coupling housing.
You should hear a click.
6
While holding the retaining
wings of the infusion set,
carefully remove the backing
paper under the needle.
10
Ensure the adhesive tape
is secured thoroughly onto
your skin.
⚠ Caution: DO NOT attempt to
straighten the adhesive if curled.
3
To attach the infusion set
tubing to the t:lock connector
on the cartridge, twist the
connector clockwise until tight,
then twist another quarter of
a turn to ensure a secure
connection.
7
Gently twist and pull off the
guard from the steel needle.
11
Remove the backing paper
from the coupling housing
and attach it to a location
that allows for easy access.
⚑ Note: Ensure that the tubing
between the introducer needle
and housing is not too tight.
Fill Tubing
START
Fill Tubing
0
Amount Filled u
4 4
Fill your tubing according to
the instructions detailed in
the Tandem Diabetes Care
insulin pump user guide.
⚠ Caution:
DO NOT fill tubing
while the infusion set is connected
to your body.
8
Pinch the skin at your
selected insertion area with
one hand to help lift the skin
away from any muscle tissue.
Load
Change Cartridge
Fill Tubing
Fill Cannula
Site Reminder Press to Turn On
12
Skip the "Fill Cannula" step
in the load process, set your
Site Reminder for 48 hours,
depending on your insulin
type, and resume insulin.
⚠ Caution:
ALWAYS check glucose
levels 1-2 hours after inserting to
make sure it's working properly.
