Connecting SimpleDrive

Connect SimpleDrive to your computer using either the USB or FireWire 400 port. SimpleDrive does
not support simultaneous use of both ports.
Connect one end of the
1
provided USB or FireWire
cable to the corresponding
port on the back of
SimpleDrive.
Connect the other end of
2
the USB or FireWire cable
to the corresponding port on
your computer.
Connect the AC adapter
3
cord to the DC-IN socket on
the back of SimpleDrive.
4 Connect the power cord to
the AC adapter.
Connect the other end of the power cord to an electrical outlet or power strip.
5
6 Set the Power switch to the On position.
The Capacity Meter comes on for 10 seconds, providing a visual indication of the available
storage space on the drive.
SimpleDrive is ready to use.
D
RIVE
* SimpleDrive Deluxe models only.
Power Switch
DC-IN
FireWire 400 *
USB 2.0
AC Adapter Cord
Power Cord
