DECLARATIONS
This meter complies with Class B (1%) to EN50470 1-3
MID Approval Certificate No. 0120/SGS0280
This meter is intended to be installed in a Mechanical Environment 'M1' with Shock and
Vibrations of low significance, as per 2014/32/EU Directive.
This meter is intended to be installed in electromagnetic Environment 'E2', as per 2014/32/EU
Directive.
This meter is intended for Indoor use only.
This meter is intended for Non Condensing humidity.
Note that this meter is sealed and there are no user serviceable parts and no user
adjustments. The maintenance and repair of this meter is only permissible by RDL Meters Ltd.
GUARANTEE
This meter is guaranteed for a period of 12 months from the date of purchase, subject to the
following guarantee conditions:
This meter is covered by RDL Meters Ltd for parts and manufacturing labour.
This guarantee will not cover any Consequential losses.
This guarantee will be void under any of the following conditions:
à Removal of any seals to the case
The meter has not been installed by a competent, qualified electrician to standards that satisfy
à
the requirements of the current Institute of Electrical Engineers (IEE)
The meter has been incorrectly installed
à
The meter has been subject to a load of greater than 100 Amps
à
à The meter has been tampered with, to obtain free electricity
If returning the meter, please contact RDL Meters Ltd to report the return and to arrange an RMA
(Return Merchandise Authorisation) number. Make sure that the meter is carefully packed.
Visit: www.rdlmeters.com
2
CONTENTS PAGE NO.
1. INTRODUCTION ........................................4
1.1 Overview ...................................................4
2. TECHNICAL DATA .....................................4
2.1 Meter LED & Power Registration Security ...4
2.2 General ......................................................4
2.3 Power Supply ............................................4
2.4 Metrology ..................................................4
2.5 Environmental ...........................................4
2.6 Dimensions ...............................................4
3. NORMAL FUNCTIONAL OPERATION ......5
3.1 Normal Operation Display .........................5
3.2 Reverse Energy Detection .........................5
3.3 Aditional Displayed Information
4. FUNCTIONAL OPERATION ON
APPLICATION OF POWER............................5
4.1 Power Up Operation Display .....................5
5. APPENDIX ..................................................6
5.1 Starting Current .........................................6
5.2 Wiring Diagram & Mounting Template......... 6
CONTENTS

HOW TO ORDER

For Sales Contact:
PASS Ltd - Master Distributor
Visit: www.tester.co.uk
Tel: 01642 626 140
Email: info@tester.co.uk
For Service & Repairs Contact:
RDL Meters Ltd.
Tel: 01803 697 600
Visit: www.rdlmeters.com
RDL Meters Ltd. Unit E2 Westfield Business
Park, Long Road, Paignton, Devon, TQ4 7AU
RDL Meters Ltd. Company No: 13667532
Call: 01803 697 600
