ITALY: Tel: +39-02-66590054
E-mail: support-it@riscogroup.com
CHINA: (Hu) Tel: +86-21-52390066
E-mail: support-cn@riscogroup.com
SPAIN: Tel: +34-91-490-2133
E-mail: support-es@riscogroup.com
ISRAEL: Tel: +972-3-963-7777
E-mail: support@riscogroup.com
ELECTRICAL
Battery Type:CR123 3V Lithium Battery
Current Consumption:
11µA standby, 40 mA max
Frequency:
RWX73M86800B 868.65 MHz White
RWX73M8BR00B 868.65 MHz Brown
RWX73M8BL00B 868.65 MHz Black
RWX73M43300B 433.92 MHz White
Dead Time (HOLD ON): 2.5 minutes
Supervision Transmission: 0-255 minutes Storage temperature: -20°C—60°C (-4°F—140°F)
Modulation type: ASK
Specifications are subject to change without prior notice.
Should any questions arise please contact your supplier.
2-Way Wireless
Magnetic Door/Window
Contact with Shutter
Models: RWX73M, RWX73M8BL &
CONTACTING RISCO GROUP
TECHNICAL SPECIFICATION
Battery Life: 3 years typical
Low battery: 2.6 V
Contact Size: 32 x 35 x 72 mm (1.3 x 1.4 x 2.8 in.)
Magnet Size:16 x 11 x 72 mm (0.6 x 0.44 x 2.8 in.)
Output power: 10mW Max.
Operating temperature:
-10°C—55°C (14°F—131°F)
RF immunity: According to EN50130-4
RWX73MBR
USA: Tel: +1-631-719-4400
E-mail: support-usa@riscogroup.com
UK: Tel: +44-(0)-161-655-5500
E-mail: support-uk@riscogroup.com
FRANCE: Tel: +33-164-73-28-50
E-mail: support-fr@riscogroup.com
BELGIUM: Tel: +32-2522-7622
E-mail: support-be@riscogroup.com
ENVIRONMENTAL
1
SE
Advertisement
Table of Contents
Related Manuals for Risco RWX73M8BL
Summary of Contents for Risco RWX73M8BL
- Page 1 2-Way Wireless Magnetic Door/Window Contact with Shutter Models: RWX73M, RWX73M8BL & RWX73MBR CONTACTING RISCO GROUP ITALY: Tel: +39-02-66590054 USA: Tel: +1-631-719-4400 E-mail: support-it@riscogroup.com E-mail: support-usa@riscogroup.com CHINA: (Hu) Tel: +86-21-52390066 UK: Tel: +44-(0)-161-655-5500 E-mail: support-cn@riscogroup.com E-mail: support-uk@riscogroup.com SPAIN: Tel: +34-91-490-2133 FRANCE: Tel: +33-164-73-28-50 E-mail: support-es@riscogroup.com...
- Page 3 Optional | En option | Opzionale | Opcional |Tillval Magnet spacers | Entretoises aimant | Distanziali per magneti | Espaciadores de magnéticos | Distanser magnet • RAX73MSB000A (x 10): brown | marron | marrone | marron |(brun • RAX73MS0000A (x 10): white | blanc | bianco | blanco |vit •...
- Page 4 GENERAL DESCRIPTION The RWX73M is a 2-way supervised transmitter that combines the Magnetic/Door Contact (against opening doors and windows) with an additional universal input or shutter. The RWX73M operates with RISCO’s 2-way wireless systems. MAIN FEATURES LED INDICATION • Communication: Bi-directional •...
-
Page 5: Descrizione Generale
RWX73M funziona con i sistemi radio bidirezionali di RISCO Group. CARATTERISTICHE PRINCIPALI INDICATORE LED •... -
Page 6: Modo Di Funzionamento
Passo 3: Scegliere la posizione di installazione 1. Scegliere una posizione di installazione che garantisca una buona qualità di comunicazione e la vicinanza al dispositivo da interfacciare all’ingresso. RISCO consiglia di posizionare il dispositivo alla massima altezza possibile. 2. Fissare temporaneamente il dispositivo nel punto prescelto usando del nastro biadesivo. - Page 7 NOTE: • Si raccomanda di montare il trasmettitore sulla parte non movibile (telaio della porta/finestra), e il magnete sulla parte movibile. • I distanziali vengono forniti separatamente (Fig. 6). • Il riferimento sull’involucro del magnete deve essere allineato con il riferimento situato sul contenitore del trasmettitore (Fig.
-
Page 8: Description Generale
Etape 3: Choix de l'emplacement de l'installation 1. Choisissez l'emplacement le mieux adapté pour assurer la qualité de la communication, tout en restant au plus près du détecteur filaire prévu. RISCO recommande de placer l’unité en position la plus haute possible. - Page 9 2. Fixez provisoirement l'appareil à ce point à l'aide d'un ruban adhésif double face. 3. Générez un signal d'alarme (en ouvrant ou en fermant momentanément les bornes d'entrée) et vérifiez que le récepteur a bien reçu le signal. Si le signal d'alarme n'est pas détecté, replacez le transmetteur et essayez à...
- Page 10 El RWX73M es un transmisor bidireccional supervisado que combina un contacto magnético para la protección de puertas y ventanas con una entrada universal adicional o pulsos. El RWX73M funciona con los Sistemas bidireccionales de RISCO Group. INDICACIÓN DEL LED CARACTERÍSTICAS PRINCIPALES •...
- Page 11 Paso 3: Selección de la Ubicación de Montaje 1. Elegir la ubicación más adecuada para conseguir una buena calidad de comunicación, y cerca del detector cableado (si está previsto). RISCO le recomienda ubicar la unidad a la máxima altura posible.
-
Page 12: Allmän Beskrivning
EN 50131-2-6 Grado 2 Clase Ambiental II ALLMÄN BESKRIVNING RWX73M är en 2-vägs övervakad universal magnetkontakt med trådbunden ingång för extern kontakt eller rulljalusi. RWX73M är kompatibel med trådlösa 2-vägs system från RISCO LED-INDIKERING HUVUDFUNKTIONER • Vid lyckad inlärning: kort blixtsekvens •... - Page 13 DRIFTSKANALER RWX73M detekterar status på IN1 och magnetkontaktens reed-relä. I normalt arbetsläge sänds larm vid påverkan av ingång eller magnet. Återställning sänds omedelbart när IN2 eller magnet återgår. OBS: Om enheten konfigureras för rulljalusi kommer magnetkontakten att vara urkopplad. INSTALLATION Steg 1: Inlärning av sändaren X73M måste läras in till systemet innan den kan tas i bruk.
-
Page 14: Tekniska Specifikationer
EN 50131-2-6 Grade 2 Miljöklass II SSF 1014 v4, & Larmklass R. RED COMPLIANCE STATEMENT Hereby, RISCO Ltd. declares that this product is in compliance with the essential requirements and other relevant provisions of Directive 2014/53/EU. The declaration of conformity may be consulted at www.riscogroup.com Dichiarazione di Conformità... - Page 15 RISCO, for a period of (i) 24 months from the date of delivery of the Product (the “Warranty Period”). This Limited Warranty covers the Product only within the country where the Product was originally purchased and only covers Products purchased as new.
- Page 16 RISCO in conjunction with the Product (with or without the RISCO brand), including, but not limited to system software, as well as P2P services or any other service made available by RISCO in relation to the Product, are not covered under this Limited Warranty.
