INSTRUCTION MANUAL
MAGNETIC LIGHTS
VT-42112
MAGNETIC FLEXIBLE TUBE
INTRODUCTION & WARRANTY
Thank you for selecting and buying V-TAC product. V-TAC will serve you the best. Please read these instructions
carefully before starting the installation and keep this manual handy for future reference. If you have any another
query, please contact our dealer or local vendor from whom you have purchased the product. They are trained
and ready to serve you at the best. The warranty is valid for 3 years from the date of purchase. The warranty
does not apply to damage caused by incorrect installation or abnormal wear and tear. The company gives no
warranty against damage to any surface due to incorrect removal and installation of the product. The products
are suitable for 10-12 Hours Daily operation. Usage of product for 24 Hours a day would void the warranty. This
product is warranted for manufacturing defects only.
In case of any query/issue with the product, please reach out to us at: support@v-tac.eu
For More products range, inquiry please contact our distributor or nearest dealers.
V-TAC EUROPE LTD. Bulgaria, Plovdiv 4000, bul.L.Karavelow 9B
VT-42112
MAGNETIC FLEXIBLE TUBE
MULTI-LANGUAGE
MANUAL QR CODE
Please scan the QR code to
access the manual in multiple languages.
TECHNICAL DATA
INPUT
MODEL
SKU
POWER
LUMENS
VOLTAGE
10277
DC 48V
11W
1270 Lm
VT-42112
10278
DC 48V
11W
1320 Lm
10279
DC 48V
23W
2760 Lm
VT-42024
10280
DC 48V
23W
2850 Lm
WARNING
1.
2. Installation must be performed by a certified person.
3. Proper grounding should be ensured throughout the installation.
4. Do not connect with AC 220V directly. Use DC 48V transformer.
5. For Indoor use only
This marking indicates that this
product should not be disposed of
with other household wastes.
Caution, Risk of electric shock
BEAM
IP
BODY
CRI
DIMENSION
ANGLE
RATING
TYPE
200°
80
IP20
PC
1066x150x26mm
200°
80
IP20
PC
1066x150x26mm
200°
80
IP20
PC
2066x150x26mm
200°
80
IP20
PC
2066x150x26mm
the installation.
Non-replaceable light source
Non-replaceable control gear
