Dimensional data
*
Recommended height, unless different regulations are specified.
*
Installation
1
The RJ45 cable must be at least
200 mm long
Uninstall
2
1
BTicino SpA – Viale Borri, 231 – 21100 Varese – Italy – www.bticino.com
211 mm
3
28 mm
12 mm
2
148 mm
120,5 mm
50 mm
60 mm
83,5 mm
3
4
4
04/21-01 PC
373002
373004
