Note: E.S.E. Pod Holder Adaptable. Not included with all models. Please visit www.mrcoffee.com for more details.
Control panel
Understanding the Controls
Your control panel is divided into 2 parts. The left side of each button indicates the automatic brewing functions (See D in Figure). The right side indicates the manual function of each button (See E in Figure).
Lights Indicate:
Espresso (Button A):
Cappuccino (Button B):
Latte (Button C):
NOTE: Please read the rest of the instructions before operating the MR. COFFEE® Café Barista (espresso, cappuccino & latte maker).
You have selected the new and innovative Mr. Coffee® Café Barista (espresso, cappuccino & latte maker). This unique appliance has been designed to help you prepare delicious espressos, cappuccinos and lattes quickly, conveniently, and automatically with the touch of a button.
FOR BEST BREW
When using appliance, be sure to use espresso grounds. If grinding beans, be sure to purchase espresso beans.
ESPRESSO
A unique method of coffee brewing in which hot water is forced through finely ground coffee. Popular in Europe, it is a far richer and more full-bodied brew than regular drip coffee. Because of its richness, espresso is usually served in 44 to 59 mL (1.5 to 2 oz.) portions, in demitasse cups.
CAPPUCCINO
A drink made with about 1/3 espresso, 1/3 steamed milk, and 1/3 frothed milk.
LATTE
A drink made with about 1/4 espresso and 3/4 steamed milk.
Please read ALL of the instructions, cautions, notes and warnings included in this instruction manual carefully before you begin to use this appliance. When this unit is used, some parts and accessories get hot and need to cool down. Proper care and maintenance will ensure the long life of the MR. COFFEE® Café Barista and its trouble-free operation. Save these instructions and refer to them often for cleaning and care tips.
HOW TO SELECT THE RIGHT CUP
Please make sure to select your cup according to the following chart:
BEVERAGE | AMOUNT | |
Espresso | Single ( ) Double ( ) | 1.25 oz 2.5 oz |
Cappuccino | Single ( ) Double ( ) | 6 oz 10 oz |
Latte | Single ( ) Double ( ) | 12 oz 15 oz |
NOTE: The total amount of the beverage can vary depending on the type of milk used and Froth Control Knob setting.
THE COFFEE
The coffee should be freshly ground and dark roasted. You may want to try a French or Italian roast ground for espresso. Pre-ground coffee will only retain its flavor for 7 – 8 days, provided it is stored in an airtight container and in a cool, dark area. Do not store in a refrigerator or freezer. Whole beans are recommended to be ground just before use. Coffee beans stored in an airtight container will keep its flavor for up to 4 weeks.
THE GRIND
This is a vital step in the espresso making process if you are grinding your own coffee and takes practice. The coffee must be of a fine grind.
Be sure to use a quality grinder for uniform consistency. A conical or burr mill grinder is recommended for a consistent and fine espresso grind.
Unit must be primed prior to first use.
FILLING THE WATER RESERVOIR
FILLING THE MILK RESERVOIR
If you plan to prepare cappuccino or latte, remove the milk reservoir from the unit. Lift the lid and pour the quantity of cold milk you estimate you will need. Do not fill past the "MAX" line. When done, place the milk reservoir back in the unit ensuring it fits tightly and the Cappuccino and Latte buttons are illuminated or pulsing.
NOTE: Be sure to firmly push Milk Reservoir into unit until Cappuccino and Latte buttons light illuminate/pulse.
NOTE: You can use any type of milk, i.e. whole milk, low fat milk, organic or soy milk.
CHOOSING THE FILTER
Select the filter to be used as follows:
INSERTING THE FILTER
NOTE: To remove and clean the filter, turn filter to the left or right to align the filter notch with the groove inside the porta-filter.
Make sure the filter has cooled before attempting to remove the filter.
FILLING WITH COFFEE
PLACING THE PORTA-FILTER
PLACING THE CUP(S)
When brewing cappuccino or latte, make sure to adjust the frothing tube lever to aim the frothed milk dispensing tube inside your cup.
TURNING THE UNIT ON
The 3 control panel lights will start pulsing during heating until the brew and steam heaters reach the perfect temperature. Once these lights become solid, the unit is ready to use.
NOTE: It is normal for the Espresso function to be ready before the Cappuccino and Latte functions.
NOTE: If you leave your unit on for 15 minutes without using, your unit will go into sleep mode. Press any button to reactivate.
PREPARING ESPRESSO
The unit will start brewing the espresso according to your selection. The unit will turn off automatically and the lights will become solid indicating that the cycle has been completed. Your delicious espresso is ready to be enjoyed.
NOTE: To brew less coffee than the preset serving, press the function button to stop the brewing process when the amount of coffee desired is reached.
PREPARING CAPPUCCINO
Prior to preparing your cappuccino, adjust the amount of froth milk according to your preference by turning the Froth Control Knob to the right for more froth and to the left for less froth. For Cappuccino, it is recommended that the Froth Control Knob be turned to the Cappuccino setting.
NOTE: The froth intensity can be adjusted during the brewing cycle.
NOTE: For a small cup, use the single shot filter. For a large cup, use the double shot filter.
Make sure to clean the Frothed Milk Dispensing Tube after use. See Cleaning instructions for instructions.
PREPARING LATTE
Prior to preparing your latte, adjust the amount of froth according to your preference by turning the Froth Control Knob to the right for more froth and to the left for less froth. For Latte, it is recommended that the Froth Control Knob be turned to the Latte setting.
NOTE: For a small cup, use the single shot filter. For a large cup, use the double shot filter.
Make sure to clean the Frothed Milk Dispensing Tube after use. See Cleaning instructions for instructions.
TO ADD ADDITIONAL FROTHED MILK / FROTH MILK SEPARATELY
The Mr. Coffee® Café Barista also allows you to manually add more frothed milk to your beverage or froth milk separately. To add more frothed milk to your beverage, place your beverage on the unit and ensure the Frothed Milk Dispensing Tube is aimed towards the center of your cup. Next, Press and Hold the Cappuccino Button "" for 3 seconds and the unit will begin to add more frothed milk. When done, press the Cappuccino Button "" once again to stop the unit. For frothing milk separately, follow the same instructions but place an empty cup on the unit instead. The frothed milk can be used for macchiato, hot chocolate, chai latte, etc.
CLEANING THE MILK RESERVOIR AND FROTHED MILK DISPENSING TUBE
Once you are done preparing your beverage with milk, you can either store the unit's milk reservoir with milk directly in the refrigerator OR completely clean the milk reservoir.
If storing your milk reservoir with milk in refrigerator, follow these cleaning instructions:
If completely cleaning milk reservoir, follow these cleaning instructions:
CLEANING THE PORTA-FILTER, FILTER AND BREW HEAD
Some of the metal parts might still be hot. Do not touch them with your hands until they have cooled.
CLEANING THE WATER RESERVOIR
Discard the remaining water by removing the reservoir and turning it upside down over the sink. It is recommended to empty the water reservoir between uses. Wash the water reservoir with soapy water, rinse it well and wipe it dry. Do not wash the water reservoir in the dishwasher.
DEEP CLEANING THE FILTER
Make sure to deep clean your filer every 90 days for optimal brewing performance. Follow these disassembly instructions and rinse the pieces in a large bowl of warm water. Once rinsed thoroughly, wipe dry and reassemble.
CLEANING THE UNIT
DELIMING
Mineral deposits built-up in the unit will affect the operation of the appliance. Your appliance must be delimed when you begin to notice an increase in the time required to brew espresso, or when there is excessive steaming. Also, you may notice a build-up of white deposits on the surface of the brew head. The frequency of cleaning depends upon the hardness of the water used. The following table gives the suggested cleaning intervals.
SUGGESTED CLEANING INTERVALS
Type of Water | Cleaning Frequency |
Soft Water (Filtered Water) | Every 80 Brew Cycles |
Hard Water (Tap Water) | Every 40 Brew Cycles |
TO DELIME WATER RESERVOIR:
TO DELIME INTERNAL PARTS:
PROBLEM | CAUSES | SOLUTIONS |
Coffee does not come out |
|
|
Coffee comes out around the edge of the porta-filter |
|
|
Milk is not foamy after frothing or it is not coming out of the frothing tube. |
|
|
Coffee comes out too quickly |
|
|
Coffee is too weak |
|
|
The three control panel lights are flashing alternatively |
|
|
Cappuccino and/ or Latte control button lights do not illuminate. |
|
|
Water is not being pulled in from the water reservoir. |
|
|
Do you still have questions? You can call us toll-free at the Consumer Service Department, 1-800-MR COFFEE (1-800-672-6333) or you can visit us at www.mrcoffee.com.
Replacement Parts
Repairs
If your Café Barista (espresso, cappuccino & latte maker) requires service, do not return it to the store where you purchased it. All repairs and replacements must be made by Sunbeam or by an authorized MR. COFFEE® Products Service Center. If you live in the U.S. or Canada, please call us at the following toll-free telephone numbers to find the location of the nearest authorized service center:
U. U.S. 1-800-MR COFFEE (1-800-672-6333) Canada 1-800-667-8623
You may also visit our website at www.mrcoffee.com for a list of service centers. To assist us in serving you, please have the model number and date of purchase available when you call. The model number is on the bottom of the unit.
We welcome your questions, comments or suggestions. In all your communications, please include your complete name, address and telephone number and a description of the problem.
When using electrical appliances, basic safety precautions should always be followed to reduce the risk of fire, electric shock and/or injury to persons, including the following:
SAVE THESE INSTRUCTIONS
THIS UNIT IS FOR HOUSEHOLD USE ONLY.
POWER CORD INSTRUCTIONS
POLARIZED PLUGS
This appliance has a polarized plug, (one blade is wider than the other). As a safety feature to reduce the risk of electrical shock, this plug is intended to fit in a polarized outlet only one way. If the plug does not fit fully in the outlet, reverse the plug. If it still does not fit, contact a qualified electrician. Do not attempt to defeat this safety feature or modify the plug in any way. If the plug fits loosely into the AC outlet or if the AC outlet feels warm do not use that outlet.
CORRECT USE OF GROUND COFFEE FOR ESPRESSO MAKERS
Do not use sugar roasted* ground coffee or sugar roasted coffee beans as these will clog the filter and damage the appliance. If sugar roasted coffee is accidentally used, stop using the unit and bring it to the closest service center for maintenance.
We recommend descaling the machine periodically to keep it in good working condition. Contact us toll-free at the Consumer Service Department, 1-800-MR COFFEE (1-800-672-6333) to learn about this process.
(*) GROUND WITH SUGAR
© 2016 Sunbeam Products, Inc. doing business as Jarden Consumer Solutions.
All rights reserved. Distributed by Sunbeam Products, Inc. doing business as Jarden Consumer Solutions, Boca Raton, Florida 33431.
U.S. 1-800-MR COFFEE (1-800-672-6333) Canada 1-800-667-8623
Visit us at www.mrcoffee.com
You will find exciting and entertaining tips and ideas, including great recipes!
www.mrcoffee.com
