SERVICE MANUAL
DIGITAL VIDEO CAMERA
Regarding service information other than these sections, refer to the GR-DVL510U service manual (No. 86601).
Also, be sure to note important safety precautions provided in the service manual.
SPECIFICATIONS
Camcorder
For General
Power supply
: DC 11.0 V } (Using AC Adapter)
DC 7.2 V } (Using battery pack)
Power consumption
LCD monitor off, viewfinder on : Approx. 4.3 W
LCD monitor on, viewfinder off : Approx. 5.3 W
Video light
: Approx. 3.5 W
Dimensions (W x H x D)
: 83 mm x 97 mm x 188 mm (3-5/16" x 3-7/
8" x 7-7/16")
(with the LCD monitor closed and the
viewfinder pushed down)
Weight
: Approx. 590 g (1.3 lbs)
Operating temperature
: 0°C to 40°C (32°F to 104°F)
Operating humidity
: 35% to 80%
Storage temperature
: –20°C to 50°C (–4°F to 122°F)
Pickup
: 1/4" CCD
Lens
: F 1.8, f = 3.6 mm to 36 mm, 10:1 power zoom lens
Filter diameter
: ø37 mm
LCD monitor
: 2.5" diagonally measured, LCD panel/TFT
active matrix system
Viewfinder
: Electronic viewfinder with 0.24" black/white
LCD
Speaker
: Monaural
For Digital Video Camera
Format
: DV format (SD mode)
Signal format
: NTSC standard
Recording/Playback format: Video: Digital component recording
: Audio: PCM digital recording, 32 kHz 4-
channel (12-bit), 48 kHz 2-channel (16-bit)
Cassette
: Mini DV cassette
Tape speed
: SP: 18.8 mm/s
LP: 12.5 mm/s
Maximum recording time : SP: 80 min.
(using 80 min. cassette)
LP: 120 min.
GR-DVL512U
(The specifications shown pertain specifically to the model GR-DVL512U)
This service manual is printed on 100% recycled paper.
COPYRIGHT © 2001 VICTOR COMPANY OF JAPAN, LTD.
For Digital Still Camera
Storage media
: SD Memory Card/MultiMediaCard
Compression system
: JPEG (compatible)
File size
: VGA (640 x 480 pixels)
Picture quality
: 2 modes (FINE/STANDARD)
Approximate number of storable images
with memory card [8 MB] (provided)
FINE
: 100
STANDARD
: 200
with memory card [16 MB] (optional)
FINE
: 200
STANDARD
: 400
with memory card [32 MB] (optional)
FINE
: 400
STANDARD
: 800
with memory card [64 MB] (optional)
FINE
: 800
STANDARD
: 1600
For Connectors
: Y : 1 V (p-p), 75 Ω, analog
S-Video
C : 0.29 V (p-p), 75 Ω, analog
AV
: 1 V (p-p), 75 Ω, analog
Video output
Audio output
: 300 mV (rms), 1 kΩ, analog, stereo
DV
Output/input
: 4-pin, IEEE 1394 compliant
USB
: 5-pin
EDIT
: ø3.5 mm, 2-pole
AC Adapter AP-V10U
Power requirement
U.S.A. and Canada
: AC 120 V`, 60 Hz
Other countries
: AC 110 V to 240 V`, 50 Hz/60 Hz
Output
: DC 11 V } , 1 A
Dimensions (W x H x D)
: 59 mm x 31 mm x 84 mm (2-3/8" x 1-1/4" x 3-5/16")
Weight
: Approx. 130 g (0.29 lbs.)
Specifications shown are for SP mode unless otherwise indicated. E &
O.E. Design and specifications subject to change without notice.
No. 86627
April 2001
