USER GUIDE
MID-7604/7602 P
Contents
National Instruments™, NI™, and ni.com™ are trademarks of National Instruments Corporation. Product and company names mentioned herein are
trademarks or trade names of their respective companies.
322454C-01
Copyright © 1999, 2001 National Instruments Corp. All rights reserved.
Download from Www.Somanuals.com. All Manuals Search And Download.
OWER
This user guide describes the electrical and mechanical aspects of the
MID-7604/7602 power drive and how to use the MID-7604/7602 with your
motion controller.
Compliance ............................................................................................. 2
Conventions ............................................................................................ 3
Introduction ............................................................................................. 4
What You Need to Get Started ............................................................... 4
Safety Information .................................................................................. 5
Front Panel Switches............................................................................... 7
Back Panel Connector Wiring................................................................. 8
Host Bus Interlock Circuit ...................................................................... 9
Front Panel LEDs.................................................................................... 9
Driver Fault Output LEDs ............................................................... 10
Driver Inhibit LEDs ......................................................................... 10
Limit Status LEDs ........................................................................... 10
Front Panel DIP Switch Settings............................................................. 11
Microstepping Selection .................................................................. 12
Output Current Settings ................................................................... 13
Inhibit Input Polarity Setting ........................................................... 15
Limit Status LED Polarity Setting ................................................... 15
Back Panel Connector Wiring................................................................. 16
Motor Power Terminal Blocks ........................................................ 16
Encoder Terminal Blocks ................................................................ 17
Limit Switch Terminal Blocks......................................................... 20
Breakpoint and Trigger Terminal Blocks ........................................ 20
Analog I/O Terminal Blocks............................................................ 21
Accessories for Optional Use.................................................................. 22
Strain-Relief Bar .............................................................................. 22
Panel-Mount Kit (Included)............................................................. 23
Amplifier/Driver Command Signals....................................................... 23
Stepper Motor Configurations ................................................................ 24
Specifications .......................................................................................... 27
D
RIVE
July 2001
