Pass the
Pass the refrigerator laterally through the access
refrigerator
door as shown in the right figure.
Door replacement
Mount them in the reverse sequence of removal after they pass through the access
door.
Feed water pipe installation
(*Dispenser model only)
Before
Automatic ice maker operation needs water pressure of 147~834 kPa (1.5~8.5
installation
kgf/cm
If water pressure does not reach the rating 147 kPa (1.5 kgf/cm
necessary to purchase a separate pressure pump for normal automatic icing and
cool water feed.
Keep the total length of the feed water pipe tube within 8 m and be careful for the
tube not be bent. If the tube is 8 m or longer it may cause trouble in water feed
owing to the drain water pressure.
Install the feed water pipe tube at a place free from heat.
Connect to potable water supply only.
Warning
Refer to instructions with water filter kit for installation.
8
2
) (That is, an instant paper cup (180 cc) will be fully filled within 3 sec.).
Installation
Max
5
4
3
2
1
TEMP
1
Min
FRZ
2
3
4
TEMP
REF
5
Max
2
) or below, it is
