Care and maintenance

Freezer
compartment
lamp
Freezer
compartment
shelf
Door rack and
support
Ice storage bin
After dispenser
is used
25

How to dismantle parts

NOTE
Dismantling is done in the reverse sequence of assembly.
•
Be sure to unplug the power plug before dismantling and assembly.
Never apply severe force to dismantle parts. Parts may be damaged.
Separate the lamp by pulling it out
pressing and rotating the lamp cover.
Turn the bulb counterclockwise. Use a 40-watt bulb
(max.) which can be purchased at a service
center.
NOTE
Not all bulbs will t your refrigerator.
•
Be sure to replace the bulb will one of the same size, shape and wattage.
The dispenser lights are LEDs that can not be changed.
•
To remove a shelf, push the shelf to the left
lift the left part of the shelf a bit
part up , and take it out.
Lift the door rack holding both sides
pull it out .
Hold the ice storage bin as shown in the right
gure and pull it out while slightly lifting it
Do not dismantle the ice storage bin unless
it is necessary.
Use both hands to remove the ice bin to avoid
dropping it.
The water collector has no self-draining
function. It should be cleaned regularly.
Remove the cover by pulling the front side of
water collector cover and dry it with a cloth.
Pull the cover fully to the front
the rear end of the cover
Clean the oor and cover with a dry cloth.
while slightly
,
, lift the right
and
.
and pull up
slightly to pull it out.
2
1
