RTZ2MAN60 2-Person Temporary Horizontal Lifeline
User Instruction Manual
This manual is intended to meet the Manufacturer's Instructions as required by the American National Standards Institute
(ANSI) Z359 and should be used as part of an employee training program as required by the Occupational Safety and Health
Administration (OSHA).
Advertisement
Related Manuals for RITZ RTZ2MAN60
Summary of Contents for RITZ RTZ2MAN60
- Page 1 RTZ2MAN60 2-Person Temporary Horizontal Lifeline User Instruction Manual This manual is intended to meet the Manufacturer’s Instructions as required by the American National Standards Institute (ANSI) Z359 and should be used as part of an employee training program as required by the Occupational Safety and Health...
- Page 2 Do not alter or intentionally misuse this equipment. • Consult RITZ SAFETY when using this equipment in combination with components or subsystems other than those described in this manual. • Do not connect rebar hooks, large carabiners, or large snap hooks to FBH dorsal D-rings as this may cause a roll-out condition and/or unintentional disengagement.
- Page 3 Application The RTZ2MAN60 2-Person Temporary HLL provides horizontal mobility for workers exposed to fall hazards and is designed as an anchorage subsystem for the attachment of up to two PFASs. The HLL is adjustable up to 60’ in length for a single span system and is designed to be used as part of a complete PFAS.
- Page 4 (those are ANSI Z359.13 compliant) and RITZ SAFETY fall arrestor connecting subsystems. Rescue: The RTZ2MAN60 2-Person Temporary HLL is part of a complete PFAS. It is not intended as a rescue device. Use of this system presents a wide variety of potential rescue scenarios. Users of this system should understand their work environment and develop a rescue plan accordingly.
- Page 5 2.8.2 Minimum Required Fall Clearance for Two Workers w/EAL Figure 4 - 2-Person Temporary HLL with EALs Minimum Fall Clearance (Two Workers) Temporary HLL with EAL Minimum Required Fall Clearance 310 lbs. Maximum User Capacity Each Max. Two Workers Find Span Length in Table Below Find Freefall Distance in Table Below Required Fall Clearance at the intersection of Span Length and Freefall Distance (see table below) A.
-
Page 6: System Requirements
Contact RITZ SAFETY if you have any questions about compatibility. Connectors must be compatible with the anchorage or other system components. Do not use equipment that is not compatible. -
Page 7: Installation And Use
If used in applications with leading edge hazards, anchorage locations must be selected so that the deflected HLL shall not encounter a leading edge in the event of a fall. For below D-ring anchor point installations, contact RITZ SAFETY. Anchorage Connector: Anchorage Connectors used as part of a PFAS should be designed for use with specified anchor points and compatible with the PFAS components and connectors to be used in the assembly of a complete PFAS. - Page 8 Section 2.7. Step 2: Install the end anchorage connectors. The RTZ2MAN60 2-Person Temporary HLL system comes with 2 pass-through anchor straps for wrapping around columns. If using pass through anchor straps, ensure strap is wrapped at least twice around the end anchorage, see Figure 9.
-
Page 9: Maintenance, Service And Storage
Pre-Use Inspection: Prior to each use the HLL system should be inspected by the user for damage, wear and to ensure the lifeline is properly tensioned. Please review the inspection checklist for inspection requirements. Inspection Frequency: Other than pre-use inspection, the RTZ2MAN60 2-Person Temporary HLL should be inspected by a competent person at least once a year. -
Page 10: Inspection Record
Inspection Record Model #: Serial #: Date of Manufacture: INSPECTION INSPECTOR COMMENTS PASS/FAIL CORRECTIVE ACTION NEEDED APPROVED BY DATE... - Page 11 Labels The labels must be present and legible.
