Water Pressure Sensor WiFi
PREWIE02
automatically created 2024.02.16, 09:33:21 @ www.aqua-scope.com/manuals
Water Pressure Sensor WiFi
Product Description
The Aqua-Scope pressure sensor detects water consumption, and leaks by
analyzing pressure waves in the water supply. It continuously records the
temperature, the water consumption, and water pressure. When leaks are detected
or when pressure or temperature thresholds are exceeded or not reached, the user
is alerted wirelessly. The device consists of two parts:
The main housing for signal processing and wireless communication with a
battery compartment.
The external sensor head is connected to the water pipe. The stainless steel
sensor head features a silicon sensor suspended in silicone oil for highly
accurate and low-noise pressure measurements. The pressure measurement
range is between 1 to 10 bar. The sensor head is installed somewhere in the
building at a standardized 1/4-inch inspection opening or with a provided T-
piece under any sink at the edge or corner valve.
The sensor can send an alarm message when predefined threshold values are
SKU: PREWIE02
Version: 1.1.0
1 / 13
Advertisement
Table of Contents
Related Manuals for Aqua-Scope PREWIE02
Summary of Contents for Aqua-Scope PREWIE02
- Page 1 SKU: PREWIE02 Version: 1.1.0 Product Description The Aqua-Scope pressure sensor detects water consumption, and leaks by analyzing pressure waves in the water supply. It continuously records the temperature, the water consumption, and water pressure. When leaks are detected or when pressure or temperature thresholds are exceeded or not reached, the user is alerted wirelessly.
-
Page 2: Installation
It is recommended to choose a location as low as possible in the apartment (ideally in the basement or on the first floor). Attention! If a pressure reducing valve (PRV) is installed, the Aqua-Scope monitoring device must be installed between the pressure reducer and the individual outlets. -
Page 3: Connecting To Wlan
5. Connect the metal hose to the top of the connector and secure it with the 19mm wrench. 6. Screw the Aqua-Scope pressure sensor head into the side opening of the connector and secure it by hand. It is not necessary to tighten it too much. - Page 4 Now, enter the SSID and WPA key of the home Wi-Fi. If you want to control your device later via the Aqua-Scope app, you need to have an Aqua-Scope account and provide this email address so that the device can be associated with your account.
-
Page 5: Device Usage
Water Pressure Sensor WiFi PREWIE02 automatically created 2024.02.16, 09:33:21 @ www.aqua-scope.com/manuals there is more information on this. The 'Save' button saves and activates the values. If they were correct, the red/green blinking stops. Otherwise, the process must be repeated with the correct SSID and WPA key. - Page 6 When the monitor is connected to the local Wi-Fi, its functions can be used through various communication methods (even parallel): 1. Mobile Phone App: You won't find the Aqua-Scope app in your phone's app store. We use a Progressive Web App (PWA, more at wikipedia.org/wiki/Progressive_web_app).
- Page 7 Water Pressure Sensor WiFi PREWIE02 automatically created 2024.02.16, 09:33:21 @ www.aqua-scope.com/manuals shortcut of the website must be added to the desktop to receive push notifications if allowed. 2. MQTT Server: When configured accordingly, the sensor's status information is sent to the configured MQTT server. The MQTT service must be active, and your own MQTT server/port/login must be set in the device.
-
Page 8: Battery Operation
Device Specific Alarms and Parameters If you want to use the device within a machine-2-machine environment (MQTT, JSON Web Services) the Aqua-Scope Developers Manual will provide you with all the required information that apply to all Aqua_Scope devices. Here you find the missing device-specific information complementing the description within the Aqua- Scope Developers Manual. -
Page 9: Scope Of Delivery
Water Pressure Sensor WiFi PREWIE02 automatically created 2024.02.16, 09:33:21 @ www.aqua-scope.com/manuals Developer Manual’. Beside the general configuration commands mentioned in the developer manual (1,3,11,16,19,27,28,29,30,31) the following device-specific configuration parameters are available: Parameter 6: Pressure Alarm Upper Threshold, set in mBar, Default is... -
Page 10: Technical Data
While the information in this manual has been compiled with great care, it may not be deemed an assurance of product characteristics. Aqua-Scope shall be liable only to the degree specified in the terms of sale and delivery. The reproduction and... -
Page 11: Declaration Of Conformity
ακόλουθη ιστοσελίδα στο διαδίκτυο: www.aqua-scope.com/ce Français Le soussigné, Aqua-Scope Technology OÜ, déclare que l'équipement radioélectrique du type PREWIE02 est conforme la directive 2014/53/UE. Le texte complet de la déclaration UE de conformité est disponible l'adresse internet suivante: www.aqua-scope.com/ce Hrvatski Aqua-Scope Technology OÜ ovime izjavljuje da je radijska oprema tipa PREWIE02 u skladu s Direktivom 2014/53/EU. -
Page 12: Disposal Guidelines
Português O(a) abaixo assinado(a) Aqua-Scope Technology OÜ declara que o presente tipo de equipamento de rádio PREWIE02 está em conformidade com a Diretiva 2014/53/UE. O texto integral da declarao de conformidade está disponível no seguinte endereo de Internet: www.aqua-scope.com/ce Română... - Page 13 Water Pressure Sensor WiFi PREWIE02 automatically created 2024.02.16, 09:33:21 @ www.aqua-scope.com/manuals Do not dispose of electrical appliances as unsorted municipal waste, use separate collection facilities. Contact your local government for information regarding the collection systems available. If electrical appliances are disposed of in landfills or dumps, hazardous substances can leak into the groundwater and get into the food chain, damaging health and well-being.
