Users and Installation Manual: Flood Sensor AQS-LoRa (FLOLWE02)
Flood Sensor AQS-LoRa
SKU: FLOLWE02
Version: 1.0.0
Product Description
The Flood Sensor detects the presence of water on its sensor pins and sends an alarm message
wirelessly when triggered. In addition, the device will regularly report the ambient temperature and
humidity and send an alarm when the readings exceed thresholds that can be set for both humidity and
temperature. The device itself is designed to sit on the floor, where 3 brass telescopic pins can detect
water on both hard floors (tiles) and soft carpets. The unit comes with a mounting bracket. It can be
screwed or taped to the wall or floor. When the main sensor is in the bracket, a super-flat sensor pad
connected by wire to the bracket is used to detect water.
When an alarm is active, the unit emits a sound and a red LED flash. The unit is powered by an internal
CR123 battery that lasts approximately 10 years in normal operation.
The device can be directly connected to an Aqua-Scope leak monitor and sends its information directly to
the Aqua-Scope system.
Connecting to Aqua-Scope Monitor
The sensor can be connected directly to an Aqua-Scope monitor without any further setup. Please scan
the QR code with your Aqua-Scope App to connect the device to your Aqua-Scope monitor.
Installation and Functions
The first step is to insert the CR123 battery. Turn the top of the sensor housing counterclockwise to open
the housing. Inside you will see the functional components of the unit:
1. CR123 battery holder. Be sure to insert the battery with the correct polarity. Inserting the battery
the wrong way will not damage the electronics, but will drain the battery without any function.
2. Button
3. Dual Color LED
4. Buzzer Sound
Copyright © 2023 Aqua-Scope Technologies, Sakala tn 7-2, 10141 Tallinn, Estonia, www.aqua- scope.com
