Users and Installation Manual: WIFI Rain Level Sensor (RANWIE01)
WIFI Rain Level Sensor
SKU: RANWIE01
Version: 1.1.0
Product Description
This rain sensor measures the amount of rain at its location in milliliters using a tipping bucket
mechanism and transmits the quantity within a 15-minute interval with an accuracy of 0.5 mm of water
column, along with the temperature. In the case of heavy rain exceeding 15 l/h, a heavy rain alarm is
triggered promptly. Both the heavy rain threshold and the measurement interval are configurable.
The device is entirely open-source, and both hardware and firmware can be downloaded from
https://github.com/aqua-scope/lorain.
The device communicates via WLAN, either to the Aqua-Scope Cloud and thus to an app on your mobile
phone or PC, or through MQTT to a server of your choice, or as a JSON object to a Smart Home Gateway.
The device is powered by two AAA batteries. The provided VARTA batteries allow for an approximate
runtime of about 2 years. A low battery level is reported wirelessly, allowing for battery replacement
before the device shuts down.
Installation and Mounting
Open the sensor by twisting the cover counterclockwise against the base of the sensor. Remove the
electronic block, which is secured on both sides by a small clip (Figure 1 and 2). On the inside of the
Copyright © 2023 Aqua-Scope Technologies, Sakala tn 7-2, 10141 Tallinn, Estonia, www.aqua- scope.com
Advertisement
Table of Contents
Related Manuals for Aqua-Scope RANWIE01
Summary of Contents for Aqua-Scope RANWIE01
- Page 1 The device communicates via WLAN, either to the Aqua-Scope Cloud and thus to an app on your mobile phone or PC, or through MQTT to a server of your choice, or as a JSON object to a Smart Home Gateway.
- Page 2 Three different methods are available for communication via Wi-Fi: 1. Conveniently through the Aqua-Scope App: Please refer to the installation and usage description of the app in the "Device Usage" section. Through the built-in web server: In the factory state, the device acts as an open Wi-Fi access point with the SSID 'Scope'.
- Page 3 When the monitor is connected to the local WLAN, its functions can be accessed through various communication channels (even simultaneously): 1. Mobile Phone App: The Aqua-Scope App is not found in the app store of your mobile phone. We use a Progressive Web App (PWA), more information at wikipedia.org/wiki/Progressive_web_app.
- Page 4 Main: ESP32-WROOM_32E (Xtensa Dual Core 32 Bit, 240 MHz, 520 KB RAM) Sub: Xtensa 16 bit Ultra Low Power RISC Wireless Connection: WIFI ESP Built-in 2.4 GHz 802.11 b/g/n Copyright © 2023 Aqua-Scope Technologies, Sakala tn 7-2, 10141 Tallinn, Estonia, www.aqua- scope.com...
- Page 5 The reproduction and distribution of the documentation and software supplied with this product and the use of its contents is subject to written authorization from Aqua-Scope. We reserve the right to make any alterations that arise as the result of technical development.
- Page 6 Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the following internet address: www.aqua-scope.com/ce Español Por la presente, Aqua-Scope Technology OÜ declara que el tipo de equipo radioeléctrico RANWIE01 es conforme con la Directiva 2014/53/UE. El texto completo de la declaracin UE de conformidad está disponible en la direccin Internet siguiente: www.aqua-scope.com/ce...
- Page 7 Português O(a) abaixo assinado(a) Aqua-Scope Technology OÜ declara que o presente tipo de equipamento de rádio RANWIE01 está em conformidade com a Diretiva 2014/53/UE. O texto integral da declarao de conformidade está disponível no seguinte endereo de Internet: www.aqua-scope.com/ce Română...
