Rampage Products 9129 Series Installation Instructions

Fabric replacement top for wrangler tj 97-06

Download this manual

BEFORE INSTALLING:

To ease installation: Install the top when temperatures are above 70 °F. The material

shrinks substantially at lower temperatures, and may be more difficult to install. The

top may have a wrinkled appearance when first installed. This is caused by the fabric

becoming wrinkled in shipping. It will relax after a few days on the vehicle.

If there is currently a soft top on the vehicle, remove it, saving any hardware removed

(screws). This should leave the bow assembly on the vehicle. Do not begin installation

without a bow assembly!

NOTE: Before assembly, the owner may want to detach the window pieces to avoid

scratching them. This merely requires pulling Velcro apart and unzipping.

INSTALLATION

1. Fold the bow assembly back and down.

2. Lay Replacement top in Jeep with inner side facing up with plastic strip (at front of

Replacement top) at rear of Jeep.

3. Pull plastic strip up onto bow assembly. Line up fourteen (14) holes in strip and

frame. Attach strip to frame with 14 screws from removal of OEM soft top. (fig. 1)

4. Fold the front corners of the Replacement top over the bow assembly. (fig. 2)

5. Flip the Replacement top up, over and out of the back of the Jeep.

6. Pull the front of the bow assembly (where the Replacement top is attached)

forward.

9129xx Fabric Replacement Top

Installation Instructions for Wrangler TJ 97-06

fig

fig 1

INCLUDED HARDWARE

Replacement top

2x fiberglass bows

fig 2

Need help?

Do you have a question about the 9129 Series and is the answer not in the manual?

Page 1 9129xx Fabric Replacement Top Installation Instructions for Wrangler TJ 97-06 INCLUDED HARDWARE Replacement top 2x fiberglass bows BEFORE INSTALLING: To ease installation: Install the top when temperatures are above 70 °F. The material shrinks substantially at lower temperatures, and may be more difficult to install. The top may have a wrinkled appearance when first installed.
Page 2 7. Loosely latch the TOP at the front with the two (2) interior latches as follows: For each latch, push the handle up against the TOP and hold. Push the tab on the Latch arm forward into the slot in the Jeep frame. Release the Latch handle. 8.
Page 3 13. At the rear of the Jeep, insert the edge of the TOP into a groove in the Factory Retaining Bar. Slide the Bar across the rear of the TOP, capturing its rear edge. (fig’s. 7 and 8) fig . 7 fig.
Page 4 Warranty Information Rampage products, Inc. warrants to the original purchaser of any top it manufactures, that the top will be free of defects in material or workmanship for a period of 1 year from date of purchase. Such obligations under this warranty shall be limited to the repair or replacement, at Rampage products discretion, of any assembly or parts which, upon examination by Rampage products, Inc.
