United Electric Controls provides these installation
and maintenance instructions for the UE Vanguard
WirelessHART toxic & combustible gas detector solely.
The end-user is responsible for maintaining the Vanguard
WirelessHART toxic & combustible gas detector in full,
operational condition.
ALL WARNINGS MUST BE THOROUGHLY READ,
UNDERSTOOD AND FOLLOWED.
MISUSE OF THIS DEVICE AND FAILURE TO ADHERE TO ALL
WARNINGS COULD RESULT IN:
• THE DEVICE NOT PERFORMING AS INTENDED,
• RISK OF EXPLOSION,
• RISK OF LOSING CONSCIOUSNESS OR DEATH.
The following symbols are used within this document:
International Hazard Warning symbol. Directions require strict
adherence.
A
International Toxic Hazard symbol. Exposure may lead to loss
of consciousness or death.
International Flammable Material Hazard symbol. Exposure
to fl ammable materials in closed areas may lead to explosion,
loss of consciousness or death.
VANGUARD
WirelessHART® Toxic & Combustible Gas Detector
P/N: TCD50HXY
Installation and Operation Instructions
Please read all instructional literature carefully and thoroughly before starting.
Refer to the final page for the Warranty.

TABLE OF CONTENTS

1.1 Device Overview ...........................................................
1.2 Device Packaging .......................................................... 2-3
1.3 Device Approvals .......................................................... 3
2.1 Battery Installation ....................................................... 4
2.2 Sensor Installation .......................................................
2.3 Sensor Placement Considerations ............................. 5-6
2.4 Sensor Cross Sensitivity ..............................................
2.5 Classifi ed Area Installation .........................................
2.6 Field Mounting .............................................................. 6-8
2.8 Antenna Placement Considerations .......................... 8
2.9 Network Confi guration ................................................ 9-11
3.1 Normal Operation .......................................................
3.2 Sensor Calibration & Bump Test ................................ 11-12
3.3 Programming Mode ..................................................... 13-14
4.1 Sensor Replacement .................................................... 15
4.2 Battery Replacement ...................................................
5.1 Hardware ....................................................................... 16
5.2 Wireless Communication ............................................
6.0 Dimensional Drawings .......................................................
7.1 Front Cover Nameplate ............................................... 18
7.2 Back Cover Nameplate ................................................
8.0 Warnings French Translations ........................................
1
2
4-5
6
6
11
15
16-17
17
18
19
02/02/2024
IM_TCD50 12
