Assembly Instructions
SAN MARCOS ARMCHAIR
NATURAL
SKU-63042
6
Thank you for your purchase. If you have any questions pertaining to the assembly of this
furniture piece, please contact the nearest World Market store. If you are not near a store,
please call our customer service call center toll free at 877-967-5362 for assistance.
ALL PRODUCTS SOLD AT WORLD MARKET ARE NOT
FOR COMMERCIAL USE AND ARE INTENDED FOR
RESIDENTIAL USE ONLY.
PAGE 1
2023.10.09

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SAN MARCOS 630426 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for World Market SAN MARCOS 630426

Summary of Contents for World Market SAN MARCOS 630426

  • Page 1 Thank you for your purchase. If you have any questions pertaining to the assembly of this furniture piece, please contact the nearest World Market store. If you are not near a store, please call our customer service call center toll free at 877-967-5362 for assistance.

  • Page 2: Component List

    Component List Label Picture Description Back Frame Seat Frame Left Arm Right Arm Seat Cushion Back Cushion Hardware List Label Description M6*50 Spring Washer Flat Washer Tool List Label Description Allen Ke PAGE 2...

  • Page 3: Assembly Preparation

    Assemble on a clean non-marring surface (such as the product’s packing foam). Do not discard any packaging until the product has been fully assembled. In case of missing parts, please contact your nearest World Market store or call our customer service call center at 1-877-967-5362.

  • Page 4: Assembly Steps

    Assembly Steps Step 1 H-1 Bolt x 2 H-2 Spring Washer x 2 H-3 Flat Washer x 2 T-1 Allen Key Carefully lay Back Frame (A) down onto a padded,non marring surface. Align holes in Seat Frame (B) with receiving holes in Back Frame (A) and secure all 2 mounting points with Allen Bolts (H-1), Spring Washers (H-2) and Flat Washers (H-3) using provided Allen Key (T-1), stacking the hardware in the order as shown.
  • Page 5 Assembly Steps Step 3 H-1 Bolt x 4 H-2 Spring Washer x 4 H-3 Flat Washer x 4 T-1 Allen Key Secure the Right Arm (D) to the assembly with the Bolts (H-1), Spring Washers (H-2) and Flat Washers (H-3) using the provided Allen Key (T-1), staking the hardware in the order as shown.
  • Page 6 Assembly Steps Step 5 H-1 Bolt x 4 H-2 Spring Washer x 4 H-3 Flat Washer x 4 T-1 Allen Key Secure the Left Arm (C) to the assembly with the Bolts (H-1), Spring Washers (H-2) and Flat Washers (H-3) using the provided Allen Key (T-1), staking the hardware in the order as shown.
  • Page 7 Outdoor Warnings All products sold at World Market are not for commercial use and are intended for residential use only. IMPORTANT: ALWAYS store furniture or use appropriate furniture covers during cold or inclement weather or during periods of non-use. Outdoor Care & Maintenance DO NOT put hot items directly on furniture surface.
  • Page 8 Customer Service Call Center, Toll Free at 877-967-5362. For valid warranty claims, World Market will repair or replace the product, or offer a full or par�al credit, in the sole discre�on of World Market. This LIMITED ONE-YEAR WARRANTY gives you specific legal rights and you may also have other rights which vary from state to state.
