COSORI CFD-P501-SUS - Premium Mini 5-Tray Food Dehydrator Manual

Get Creative with COSORI

Download the free VeSync app to access original recipes and video tutorials from.2 the COSORI chefs, interact with our online community, and more!

explore our digital recipe gallery
cosori.com

enjoy weekly, featured recipes
made exclusively by our in-house chefs

Package Contents

1 x Mini Stainless Steel Food Dehydrator
5 x Tray
1 x Fruit Roll Sheet
1 x Mesh Screen
1 x Recipe Book & Quick Start Guide
1 x User Manual

Specifications

GETTING TO KNOW YOUR PRODUCT

Your COSORI Mini Food Dehydrator features an automatic fan, which circulates warm air horizontally to evenly and quickly dry food. Dried foods are a great treat to snack on because they keep most of their nutritional value and flavor. Dehydrating is the perfect way to preserve snacks, fruit, vegetables, bread, and even flowers.

Device Diagram

1. Door
2. Control Panel
3. Housing
4. Fan
5. Power Cord
6. Mesh Screen
7. Trays
8. Fruit Roll Sheet
9. Air Outlet
10. Air Inlet

Display

Diagram Control Panel

Display

Controls

• Tap START/STOP to start or stop the dehydrator
• Tap TEMP/TIME once and use the + and - buttons to change the temperature
• Tap TEMP/TIME a second time and use the + and - buttons to change the time
• Tap the dehydrating function (JERKY, FRUIT, VEG, YOGURT) you want to use. The dehydrator will automatically change to the function's default settings (see Dehydrating Functions).

BEFORE FIRST USE

Setting Up

1. Remove and discard all packaging from the dehydrator and its accessories
2. Clean the housing, trays, and accessories with a damp cloth
   Note: The trays are dishwasher-safe. Do not wash the mesh screen or fruit roll sheet in a dishwasher.
3. Place the dehydrator on a solid, level surface. Plug in place the trays inside the dehydrator
4. Tap TEMP/TIME and use the + button to adjust temperature to 176°F. Tap TEMP/TIME again and use the - button to adjust time to 30 minutes
   Note: The default setting is 130°F (55°C) and 8 hours.
5. Press START/STOP to run the dehydrator, without adding any food. Make sure that the room has sufficient ventilation in case the dehydrator produces any smoke or smells. This is normal
6. Allow the dehydrator and trays to cool, then rinse the trays with water. Dry all parts

Note: You only need to do this the first time you use the dehydrator.

USING YOUR DEVICE

Dehydrating Functions

Your mini food dehydrator includes 4 convenient dehydrating functions: Jerky, Fruit, Vegetable, and Yogurt Functions are programmed with an ideal time and temperature for dehydrating certain foods (see Dehydrating Chart)

• Tap the button of the function you want to use. The dehydrator will automatically change to the function's default settings
• You can customize any function's time (30 min-48 hr) and temperature (95°-176°F / 35°-80°C)

To customize a function:

1. Tap the button of the function you want to customize.
2. Tap TEMP/TIME and use + or - to adjust the function's temperature. Tap TEMP/TIME again and use + or - to adjust the function's time.
3. To save, press and hold the function's button until you hear a beep.

Note:

• Press and hold the + or - buttons to rapidly increase or decrease the time or temperature.
• If you do not tap TEMP/TIME , then tapping + or - will automatically change temperature.

To reset a function:

• Press and hold both the function's button and TEMP/TIME for 3 seconds until you hear a beep.

To reset all functions:

• Press and hold both the + and - buttons for 3 seconds until you hear a beep.

Dehydrating Chart

Note: Results may vary. For recipes and inspiration, check out the Recipe Book.

Operation

Note:

• Use the dehydrator in a warm, dry room, and place on a stable, level, heat-resistant surface.
• Depending on humidity tn the air and moisture in the food, dehydration times may vary.

1. Place food on trays. Rearrange the trays to fit thicker food items. The trays can safely hold 7.7 lb / 3 5 kg of food. Avoid overloading the trays or overlapping food. Close the dehydrator door.
   Note: To avoid scratching the inside of your dehydrator, insert the tray with the smooth side of the frame facing down {Figure 1.1].

2. Plug in. The dehydrator will beep, and the display will light up for a second. The dehydrator will switch to Standby Mode, and the display will show " ".
3. Select a dehydrating function. The dehydrator will automatically change to the function's default settings.
   Note: Functions are programmed with an ideal time and temperature for dehydrating certain foods
4. Optionally, adjust the temperature and time manually. You can do this at any time
   1. Tap TEMP/TIME to adjust the temperature. Use + or - to change the temperature (95°-176°F / 35°-80°C)

Note: Temperature changes in 1°F/ 1°C increments. Press and hold + or - to change the temperature rapidly.

2. Tap TEMP/TIME again to adjust the time. Use + or — to change the time (0:30-4800)

Note: Time changes in 30-minute increments. Press and hold + or - to change the time rapidly.

5. Tap START/STOP to start dehydrating. The dehydrator will start heating START/STOP and the function's button (if selected) will stay lit, while the other buttons will turn off. Temperature and time will cycle on the display every 3 seconds for 3 minutes, then the display will only show time.
   Note: If you tap START/STOP again to stop dehydration, the timer countdown will reset and the dehydrator will enter Standby Mode.
6. When the timer finishes, the display will show "End" and the dehydrator will stop heating. The dehydrator will beep 5 times and the fan will cool down for 5 seconds.
7. Use a kitchen towel, heat resistant glove, or oven mitt to handle the trays.
8. Allow the dehydrator to cool before cleaning.

Accessories

The dehydrator comes with 2 accessories: a fruit roll sheet and a mesh screen

Fruit Roll Sheet

• Use for making fruit rolls and strips from fresh, frozen, or canned fruit. You can also use this sheet for pouring purée onto a tray.
• This sheet can also be placed on the bottom of the dehydrator to catch any dripping liquids to make cleaning easier.

Mesh Screen

• Use for foods that shrink when dried. This screen will prevent them from falling through tray grates.

How to Use Accessories

1. Place the accessory on a dehydrator tray. Place food on the accessory.
2. Once the food is dehydrated, remove the tray and lift the accessory out of the tray.
3. Remove food. Bending the mesh screen is helpful for removing sticky foods.

Tips

• Fruit and vegetables dried in the dehydrator will look different from those sold in stores. This is because homemade dried foods do not use preservatives, artificial coloring, or artificial additives
• Check out the Recipe Book and Quick Start Guide for more tips on dehydrating food.

Sound On/Off

• To turn sounds on/off, press and hold +, - , and TEMP/TIME for 3 seconds until you hear a beep.

Fan

• To use only the fan without heat, press and hold JERKY, FRUIT, and VEG for 3 seconds until you hear a beep.

Switching Temperature Units

1. Press and hold TEMP/TIME for 3 seconds.
2. The dehydrator will beep once, and the temperature unit will change from Fahrenheit to Celsius.
3. Repeat to switch back to Fahrenheit.

Standby Mode

• The dehydrator will enter Standby Mode after you plug in the appliance, after you tap START/STOP to stop dehydration, and after 3 minutes of no operation.
• The display will show " " when in Standby Mode.
• Tap any button to turn on the display and resume operation.
• To turn off the dehydrator, tap START/STOP to stop dehydration, then remove the plug from the outlet.

Overheat Protection

• Overheating is rare If the dehydrator overheats, it will automatically shut down as a safety feature and can no longer be used Contact Customer Support (see Customer Support).

CARE & MAINTENANCE

Note: Do not clean any part of the dehydrator with abrasive chemicals or metal scouring pads, as this will damage the surface.

1. Unplug the dehydrator and allow it to cool before cleaning.
2. Soak trays in hot, soapy water for easy removal of food residue.
3. If needed, use a soft brush to clean.

Note: The trays are dishwasher-safe. Do not wash the mesh screen or fruit roll sheet in a dishwasher.

4. Clean the dehydrator housing with a damp cloth.
5. Dry all parts before storing or using the dehydrator.

TROUBLESHOOTING

If your problem is not listed, please contact Customer Support (see Customer Support).

IMPORTANT SAFEGUARDS

READ AND SAVE THESE INSTRUCTIONS
Follow basic safety precautions when using the dehydrator. Read all instructions.

General Safety

• Do not touch hot surfaces.
  Use handles.
• Be cautious when handling the back of the dehydrator. This area will be hotter than the rest of the dehydrator.
• Do not immerse cord, plug, or housing in water or other liquids.
• Close supervision is necessary when any appliance is used by or near children.
• Do not allow children to clean or perform maintenance on the dehydrator unless they are supervised.
• Children should be supervised to ensure that they do not play with the dehydrator.
• Unplug when not in use, and before cleaning. Allow to cool completely before putting on or taking off parts.
• Do not use the dehydrator if it is damaged, not working, or if the cord or plug is damaged Contact Customer Support (see Customer Support).
• Using third party parts or accessories may cause injuries.
• Do not use outdoors.
• Do not place on a stove, near gas or electric burners, or in a heated oven.
• Be extremely cautious when moving the dehydrator or removing trays if they contain hot liquid, oil, or grease.
• Always use heat safe containers. Be extremely cautious if using containers that aren't metal or glass
•
  To reduce the risk of fire or electric shock, do not place oversized food or metal utensils in the dehydrator.
• Do not place paper, cardboard, or non-heat resistant plastic into your dehydrator, or any materials which may catch fire or melt.
• Do not cover the trays or any part of the dehydrator with metal foil. This will cause the dehydrator to overheat.
• To disconnect, tap START/STOP to turn off the dehydrator, then remove the p ug from the wall outlet.
• Keep the dehydrator away from flammable materials (curtains, tablecloths, etc). Use on a flat, stable, heat resistant surface away from heat sources and liquids.
• Do not store anything on top of the dehydrator while in use.
• Avoid contact with moving parts. Never place any object into the openings in the screen protecting the dehydrator fan.
• This dehydrator is not intended for use by persons (including children) with reduced physical, sensory, or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the dehydrator by a person responsible for their safety.
• This dehydrator is not intended to be operated by means of an external timer or separate remote-control system.
• Only use the dehydrator as directed in this manual.
• Not for commercial use Household use only.

Care & Maintenance

• Do not clean with metal scouring pads. Metal fragments can break off the pad and touch electrical parts, creating a risk of electric shock.
• Do not run the dehydrator for more than 48 hours at a time. After 48 hours, unplug and allow to cool for 2 hours before using again.
• Do not store any materials other than COSORI recommended accessories in the dehydrator when not in use.
• For instructions on cleaning the accessories, see Care & Maintenance.

Power & Cord

• Do not let cord (or any extension cord) hang over the edge of a table or counter, or touch hot surfaces.
• This dehydrator has a 3-prong grounding plug, and should only be used with 120V, 60Hz electrical systems in North America. Always plug into a grounded electrical outlet. Do not modify the plug in any way.

• If the power supply cord is damaged, it must be replaced by Arovast or similarly qualified persons in order to avoid an electric or fire hazard. Please contact Customer Support (See Customer Support).
• Do not use with a 220-240V outlet.


Extension Cords

• This dehydrator uses a short power supply cord to reduce the risk of entangling or tripping. Use extension cords with care.
• If a longer extension cord is used:
  • The marked electrical rating of the cord set or extension cord should be at least as great as the electrical rating of the appliance (see Specifications).
  • The cord should be arranged so that it will not drape over the countertop or tabletop where it can be pulled on by children or tripped over unintentionally.
  • The cord should be a grounding type 3-wire cord.

Electromagnetic Fields (EMF)

The COSORI Dehydrator complies with all standards regarding electromagnetic fields (EMF). If handled properly and according to the instructions in this user manual, the appliance is safe to use based on scientific evidence available today.

Note: Items marked with the following symbol may reach high temperatures and should be handled carefully

Hot surface

SAVE THESE INSTRUCTIONS

WARRANTY INFORMATION

This warranty is made by:
AROVAST CORPORATION
1202 N. Miller St., Suite A
Anaheim, CA 92806, USA

CUSTOMER SUPPORT

If you have any questions or concerns about your new product, please contact our helpful Customer Support Team.

Arovast Corporation
1202 N. Miler St., Suite A
Anaheim, CA 92806, USA

Email: support@cosori com
Toll-Free:1-888-402-1684

Support Hours
Mon-Fri, 9:00 am-5:00 pm PST/PDT

*Please have your invoice and order ID ready before contacting Customer Support.

Questions or Concerns?
Mon-Fri, 9:00 am-5:00 pm PST/PDT
support@cosori com | 1-888-402-1684
