Data Sheet - Zephyr AERO HVLS Datasheet

DATA SHEET

ZP-A E-1 P-KIT
Version 3
A E R O
H V L S I N D U S T R I A L F A N
2 .6 M TO 4 .0 M
Description
The AERO is designed for smaller commercial spaces where height and clearance may be limited. Utilising a direct drive motor the installation height is significantly reduced.
Available in a customizable span between 2.6 - 4.0 meters and with a discreet wall control, the Aero brings industrial fan tech into reach of office and domestic users while still
maintaining the benefits of a High Volume Low Speed (HVLS) system.
General
Fan diameter
Weight
Construction/materials
Operating Temperature
Power
Input Voltage
Current (A) 240V
Operating Frequency
Total Power Consumed
Motor Power (KW)
Operation
Air flow (m3/min)
RPM
Noise (dBa)
Application Area
Protection
Compliance
Warranty
Details
Ø2.6 to 4M
26 to 30kg
Extruded 6061 Aluminium, Q345b Steel motor
-20 °C to 60 °C
Details
Single-phase: 240V
2A
50Hz
500W
0.3 to 0.5KW
Details
4800 to 6800m3/min
30-120RPM
36dBa
200 to 400mSQM
Details
Motor: CE, EL, CSA; Controller: CE
5 Years
Z E P H Y R F A N S . A U
2
