Zephyr ZRC-0100 Instructions

THIS KIT INCLUDES:
(1) return air vent
1. Position and install charcoal filter bracket into
AK8000AS as shown above.
A
3. Install charcoal filter (plastic side up) into
filter bracket. Insert tab cut-out side A of
charcoal filter into bracket first. Lock
charcoal filter into place by pushing down
on side B with locking tabs.
APR10.0201 - XP022173(1)
(4) return air (1) charcoal filter
vent screws
B
ZRC-0100 Recirculating Kit Instructions
(4) bracket
screws
2. Secure filter bracket to AK8000AS body by
installing a bracket screw into each of the (4)
corners.
Turn to next page for instructions
on installing return air vent.
1
(1) charcoal filter
bracket.
