YJ001316-V02(DMP1316)
Fire Engine Play Vehicle
D
E
G
F
Note:
To Assist with your assembly, assistance videos are
available online. Go to
www.teaching.com.au
enter item code.
WARNING:
-Contains small parts, sharp points and edges.
-Adult assembly required for assembly.
-A minimum of two adults are
recommended for assembly,with three people
being of benefit for some assembly steps.
-Never leave children unattended.
-Do not place unit near high heat or moisture.
-Adult supervision recommended.
-Clean with a moist cloth.
PART LIST
A X1
Right hand
side
A
B
C
B X1
H
Left hand
side
HARDWARE
and
Φ8*55
X10
DO NOT FULLY
TIGHTEN SCREWS
UNTIL ALL SCREWS
HAVE BEEN LOOSELY
POSITIONED.
C X1
D X1
E X1
F X1
M8
m8
Φ8*75
X6
X19
X8
TIP!
BEFORE
ASSEMBLING ,
MAKE SURE THERE
ARE NO
MISSING PARTS .
G X1
H X1
I X8
J X4
M8
M8
(M5)
X6
X1
X1
NOTICE:
ELECTRIC DRILLS MAY BE USED FOR
ASSEMBLY.
ENSURE APPROPRIATE SIZE DRILL BITS
ARE USED. AND DRILL IS USED ON A
SLOW AND LOW TORQUE SETTING.
(M14)
X1
PAGE 1/5
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Wisdom YJ001316-V02
Summary of Contents for Wisdom YJ001316-V02
- Page 1 PART LIST YJ001316-V02(DMP1316) Fire Engine Play Vehicle G X1 A X1 C X1 Right hand side H X1 D X1 I X8 B X1 E X1 Left hand J X4 side F X1 HARDWARE Note: To Assist with your assembly, assistance videos are available online.
- Page 2 HARDWARE LIST(1:1) YJ001316-V02(DMP1316) MM Dia 32mm WJ-PD-LM-086 MM Dia 32mm Φ8*55 WJ-GJ-030 WJ-GJ-033 WJ-JU-317 WJ-LS-MC-013 Φ8*75 (M14) WJ-LS-031 TIP! NOTICE: BEFORE DO NOT FULLY ELECTRIC DRILLS MAY BE USED FOR ASSEMBLING , TIGHTEN SCREWS ASSEMBLY. MAKE SURE THERE UNTIL ALL SCREWS...
- Page 3 CAUTION: once assembled,carefully tip Φ8*75 Φ8*55 frame onto its side as shown.ensure ground is elther soft fall surface,or protected by a soft material such as carboard or blanket to avoid frame scratching. Φ8*75 Φ8*55 PAGE 3/5...
- Page 4 When assemble part"C"suggest that 3 persons to work together ,one person hold part"A",one person hold part"C",another one lock all screws Φ8*75 PAGE 4/5...
-
Page 5: Year Limited Warranty
Record the manufacture date here. Information is located on a label enclosed, and on the shipping carton. Place label and this sheet in an accessible place. YJ001316-V02(DMP1316) Model Number: CAUTION: Manufacture Date:...
