Summary of Contents for Propel Trampolines ENDEAVOR Series
- Page 1 WWW.RIDEPROPEL.COM OPERATION MANUAL ENDEAVOR SERIES VEHICLE IDENTIFICATION NO. The Vehicle Identi cation NO. is very important product information. Please record this number for future reference. This number helps us to provide you with accurate and ef cient service.
- Page 2 CONGRATULATIONS YOUR ALL-TERRAIN EXPLORATION JOURNEY WITH PROPEL EV ENDEAVOR BEGINS NOW! THANK YOU FOR CHOOSING US. WELCOME TO THE PROPEL EV FAMILY! Please read this User Manual carefully before riding, so you will be thoroughly famil- iar with the proper operation of your Propel EV Skateboard, its features, capabilities and limitations.
-
Page 3: Table Of Contents
QUICK NAVIGATION CONTENTS SAFETY INFORMATION COMPONENTS AND CHECK ITEMS PRE-RIDE CHECKLIST POWER ON/OFF ADJUSTMENTS AND TUNING REMOTE CONTROL ENDEAVOR S REMOTE CONTROL ENDEAVOR PRO REPLACE THE BUSHING BATTERY CARE & CHARGING SAFETY BOARD MAINTENANCE WARRANTY & MAINTENANCE ALL PICTURES ARE FOR ILLUSTRATION AND ILLUSTRATION ONLY. DIFFERENT SERIES OF ENDEAVOR PRODUCTS MAY DIFFER IN APPEARANCE AND MATERIAL. -
Page 4: Safety Information
WARNING INFORMATION READ AND UNDERSTAND OPERATION MANUAL BEFORE RIDING Read the entire Operation Manual before riding on your Propel EV Skateboard and keep it for reference. This Operation Manual contains important safety, performance and service infor- mation. Like any sport, skateboarding involves the potential risk of death, serious injury and property damage. - Page 5 WARNING TO PREVENT SERIOUS INJURY OR DEATH SAFETY MESSAGES READ AND UNDERSTAND OPERATION MANUAL BEFORE RIDING • Read all safety warnings and all instructions. • Always ride within your limits and the limits of your skateboard. ALWAYS ride at speeds at which you are comfortable without power or brakes. Your board can lose power or brakes during your ride if the available charge in the batteries in your board or in your remote is too low.
- Page 6 • A properly fitting helmet should be comfortable and not rock forward/backward or side to side. - The helmet should sit level to protect your forehead and should not have more than a 2 finger gap from your eyebrows. NEVER wear your helmet tipped back to expose your forehead or angled left or right.
- Page 7 • Propel EV Endeavor series skateboards are very powerful and the remote acceleration and brakes are highly sensitive. Be very gentle with the controls to avoid being thrown off the board.
-
Page 8: Components And Check Items
ENDEAVOR SERIES COMPONENTS AND CHECK ITEMS 1. UPPER ARM 6. BELT GUARD 11. BATTERY HOLDER 2. MAIN FRAME 7. SHOCK ABSORBER 12. ANTENNA 3. WHEEL 8. BUSHING BASE 13. CHARGING PORT 4. DECK 9. LOWER ARM 14. BELT GEAR 5. POWER BUTTON 10. -
Page 9: Pre-Ride Checklist
PRE-RIDE CHECKLIST BEFORE EACH RIDE, INSPECT YOUR BOARD AND REMOTE FOR DAMAGE. DO NOT RIDE IF DAMAGED. • Check whether the parts are deformed or worn. • Check whether the screws are loose before use and often throughout ownership. • After the skateboard is started, check for abnormal sounds. Do not use it until the cause of the abnormal sound is found and resolved. -
Page 10: Power On/Off
PUSH THE BUTTON FOR A FANTASTIC RIDE POWER ON/OFF ENDEAVOR S POWER ON: The power switch is a self-reset switch, which is installed on the upper part of the sliding plate, close to the motor side. ROLLING START: This board is equipped with “rolling start” which means you shove/push the board ahead of you for 50-100 cm and it will turn itself on (You will hear a beep). -
Page 11: Adjustments And Tuning
ADJUSTMENTS AND TUNING (1) Coil-over shocks Turn the “Tension Adjustment” ring at top of the shock clockwise to tighten, counter- clockwise to loosen. TIGHTEN TENSION ADJUSTMENT LOOSEN (2) Turning force 1. Use a 13mm wrench to loosen the LOCK NUT counterclockwise. 2. -
Page 12: Remote Control Endeavor S
REMOTE CONTROL ENDEAVOR S ODO: 00000 KM 00.0 KM/H MAX： KM/H B-PRO 1. LCD DISPLAY SCREEN 2. POWER BUTTON 3. CHARGER PORT 4. ACCELERATE/BRAKE WHEEL 5. FUNTION BUTTON ODO: 00000 KM 00.0 KM/H KM/H MAX： A. REMOTE BATTERY F. TOTAL MILEAGE B-PRO B. - Page 13 REMOTE PAIRING (ENDEAVOR S) 1. Begin with board and remote turned off. 2. Turn on board by depressing power button, release. Power button should illumi- nate. 3. Depress power button again and hold for 5-7 seconds till it begins flashing, depress. The flashing power button means it’s ready to pair.
-
Page 14: Remote Control Endeavor Pro
REMOTE CONTROL ENDEAVOR PRO 1. LCD DISPLAY SCREEN 2. ACCELERATE/BRAKE WHEEL 3. POWER ON/OFF BUTTON 4. SETTING BUTTON 5. USB CHARGING PORT 6. HANG STRAP ping: 0 A. CONNECTION STATUS F. BOARD BATTERY B. TORSION LEVEL(L/M/H) G. REMOTE BATTERY C. SPEED H. - Page 15 REMOTE SETTING (ENDEAVOR PRO) 1. Long press the power button to turn on 2. Long press the setting button to enter the parameter setting menu 3. Press the setting button to switch the menu interface 4. Press and hold the setting button until the menu name flashes to enter the setting interface 5.
- Page 16 REMOTE PAIRING (ENDEAVOR PRO) 1. Enter the Pairing menu according to the above setting method 2. Press and hold the function button until Paring flashes. After turning on the power button of the skateboard, it will automatically match. 3. “Pairing succeeded” on the remote control shows that the pairing is successful. REMOTE FUNCTIONS (1) Scroll wheel Push the wheel forward to accelerate, and push the wheel backward to slow down.
-
Page 17: Replace The Bushing
REPLACE THE BUSHING DUE TO THE DIFFERENT HEIGHTS AND WEIGHTS OF RIDERS AND THE DIFFERENT PREFERENCE NEEDS OF RIDING EXPERIENCE, PLEASE SELECT AND REPLACE THE BUSHING ACCORDING TO YOUR ACTUAL NEEDS. NOTE IMPROPER BUSHING REPLACEMENT MAY CAUSE COMPONENTS DAMAGE AND RIDER INJURY. -
Page 18: Battery Care & Charging Safety
EXPLOSION HAZARDS. SAFETY MESSAGES Only use original PROPEL EV battery packs. Never use any other battery pack with your ENDEAVOR series skateboard. TO PREVENT DEATH, SERIOUS INJURY OR PROPERTY DAMAGE: • Do not leave your battery unattended while charging. • If the battery has any issue when charging, stop charging and contact PROPEL EV SERVICE CENTER immediately. - Page 19 CAUTION OF FIRE AND WARNING EXPLOSION HAZARDS. SAFETY MESSAGES • Do not leave your battery unattended while charging. • Always allow the board to cool for 30 minutes before charging. Do not connect your board to the charger until the battery pack has had a chance to cool to an allowable charging temperature. •...
-
Page 20: Board Maintenance
BOARD MAINTENANCE YOU ARE RESPONSIBLE FOR ALL MAINTENANCE RELATING TO YOUR BOARD. FAILURE OF ANY PART DUE TO LACK OF MAINTENANCE IS NOT COVERED BY THE WARRANTY. NOTE • Always clean your bearings for the best roll and quietest/ smoothest ride. Bearings will get dirty and affect ride quality. -
Page 21: Warranty & Maintenance
WARRANTY MAINTENANCE 1. To give you a quick feedback, please make sure that there's the I.D. code which is on the remote, board's suspension and packing list in your email. 2. Within SIX MONTHS from the date of receipt by the user, non-human damage to the main body of the body can be repaired free of charge. - Page 22 WWW.RIDEPROPEL.COM EMAIL:SERVICES@RIDEPROPEL.COM / MKT@RIDEPROPEL.COM...
