- Page 1 WWW.RIDEPROPEL.COM OPERATION MANUAL ENDEAVOR SERIES VEHICLE IDENTIFICATION NO. The Vehicle Identification NO. is very important product information. Please record this number for future reference. This number helps us to provide you with accurate and efficient service.
- Page 2 CONGRATULATIONS YOUR ALL-TERRAIN EXPLORATION JOURNEY WITH PROPEL EV ENDEAVOR BEGINS NOW! THANK YOU FOR CHOOSING US. WELCOME TO THE PROPEL EV FAMILY! IF YOU NEED ANY ASSISTANCE, PLEASE DO NOT HESITATE TO REACH OUT TO US. WWW.RIDEPROPEL.COM A/S Center：SERVICES@RIDEPROPEL.COM / MKT@RIDEPROPEL.COM...
-
Page 3: Table Of Contents
QUICK NAVIGATION CONTENTS SAFETY INFORMATION COMPONENTS AND CHECK ITEMS PRE-RIDE CHECKLIST POWER ON/OFF ADJUSTMENTS AND TUNING REMOTE CONTROL ENDEAVOR S REMOTE CONTROL ENDEAVOR PRO REPLACE THE BUSHING BATTERY CARE & CHARGING SAFETY BOARD MAINTENANCE WARRANTY & MAINTENANCE PERFORMANCE PARAMETERS ALL PICTURES ARE FOR ILLUSTRATION AND ILLUSTRATION ONLY. DIFFERENT SERIES OF ENDEAVOR PRODUCTS MAY DIFFER IN APPEARANCE AND MATERIAL. -
Page 4: Safety Information
WARNING INFORMATION READ AND UNDERSTAND OPERATION MANUAL BEFORE RIDING RIDER’S RESPONSIBILITY REGARDING REGULATIONS PLEASE KEEP IN MIND: INTENDED USE SERIOUS INJURY DEATH NOT INTENDED PAGE 1... - Page 5 WARNING TO PREVENT SERIOUS INJURY OR DEATH SAFETY MESSAGES READ AND UNDERSTAND OPERATION MANUAL BEFORE RIDING ALWAYS PINCH POINT Hazard SAFETY RIDEPROPEL.COM ALWAY WEAR SUITABLE PROTECTIVE GEAR HELMET, PROTECTIVE PADS GLOVES. PAGE 2...
- Page 6 NEVER GLOVES KNEE PADS ELBOW PADS HELMET FOLLOW SKATEBOARD REGULATIONS ON AND OFF ROAD • BE AWARE OF SKATEBOARD REGULATIONS IN YOUR AREA. • DO NOT RIDE ON BUSY ROADS WITH LINE MARKINGS. • ALWAYS RESPECT PEDESTRIANS. RIDE AT YOUR OWN RISK AND USE WARNING COMMON SENSE SAFETY MESSAGES...
- Page 7 BEFORE AVOID RIDING AT NIGHT RIDING ON HILLS NOTE: DAMAGE FROM OVERLOADING THE ELECTRONICS AND THE MOTORS IS NOT COVERED BY WARRANTY. DO NOT RIDE IN WET CONDITIONS WATER DAMAGE IS NOT COVERED UNDER WARRANTY. PAGE 4...
-
Page 8: Components And Check Items
ENDEAVOR SERIES COMPONENTS AND CHECK ITEMS 1. UPPER ARM 6. BELT GUARD 11. BATTERY HOLDER 2. MAIN FRAME 7. SHOCK ABSORBER 12. ANTENNA 3. WHEEL 8. BUSHING BASE 13. CHARGING PORT 4. DECK 9. LOWER ARM 14. BELT GEAR 5. POWER BUTTON 10. -
Page 9: Pre-Ride Checklist
PRE-RIDE CHECKLIST BEFORE EACH RIDE, INSPECT YOUR BOARD AND REMOTE FOR DAMAGE. DO NOT RIDE IF DAMAGED. CHECK BOTH THE FRONT AND REAR TRUCKS AND ALL FOUR WHEELS ARE SECURE. BE SURE TO MAINTAIN YOUR TIRE PRESSURE. PROPERLY SECURE YOUR HELMET AND PROTECTIVE PADS. MAKE SURE YOUR BOARD AND REMOTE BATTERIES ARE FULLY CHARGED. -
Page 10: Power On/Off
PUSH THE BUTTON FOR A FANTASTIC RIDE POWER ON/OFF ENDEAVOR S POWER ON: ROLLING START: This board is equipped with “rolling start” which means you shove/push the board ahead of you for 50-100 cm and it will turn itself on (You will hear a beep). POWER OFF: ENDEAVOR PRO POWER ON:... -
Page 11: Adjustments And Tuning
ADJUSTMENTS AND TUNING (1) Coil-over shocks Tension Adjustment TIGHTEN TENSION ADJUSTMENT LOOSEN (2) Turning force LOCK NUT ADJUSTING ROD ADJUSTING ROD TURNING FORCE ADJUSTMENT LOCK NUT INCREASE DECREASE 13MM WRENCH H4 HEXAGON WRENCH PAGE 8... -
Page 12: Remote Control Endeavor S
REMOTE CONTROL ENDEAVOR S ODO: 00000 KM 00.0 KM/H MAX： KM/H B-PRO 1. LCD DISPLAY SCREEN 2. POWER BUTTON 3. CHARGER PORT 4. ACCELERATE/BRAKE WHEEL 5. FUNTION BUTTON ODO: 00000 KM 00.0 KM/H MAX： KM/H A. REMOTE BATTERY F. TOTAL MILEAGE B-PRO B. - Page 13 REMOTE PAIRING (ENDEAVOR S) REMOTE FUNCTIONS (1) Scroll wheel (2) Cruise control The cruise control function is an advanced function. Please use it with caution before you are familiar with it. Please do not perform special actions during the cruise control. Please end the cruise control function before you need to change gears or perform other operations.
-
Page 14: Remote Control Endeavor Pro
REMOTE CONTROL ENDEAVOR PRO 1. LCD DISPLAY SCREEN 2. ACCELERATE/BRAKE WHEEL 3. POWER ON/OFF BUTTON 4. SETTING BUTTON 5. USB CHARGING PORT 6. HANG STRAP ping: 0 A. CONNECTION STATUS F. BOARD BATTERY B. TORSION LEVEL(L/M/H) G. REMOTE BATTERY C. SPEED H. - Page 15 REMOTE SETTING (ENDEAVOR PRO) power button setting button setting button setting button acceleration brake wheel power button power button PARAMETERS AND DEFAULT VALUES Except Speed Option and Pairing functionality, all other parameters have been set at the factory according to the default value. Please do not change it at will, otherwise it will cause the remote control to display inaccurate information.
- Page 16 REMOTE PAIRING (ENDEAVOR PRO) “Pairing succeeded” REMOTE FUNCTIONS (1) Scroll wheel (2) Cruise control The cruise control function is an advanced function. Please use it with caution before you are familiar with it. Please do not perform special actions during the cruise control. Please end the cruise control function before you need to change gears or perform other operations.
-
Page 17: Replace The Bushing
REPLACE THE BUSHING DUE TO THE DIFFERENT HEIGHTS AND WEIGHTS OF RIDERS AND THE DIFFERENT PREFERENCE NEEDS OF RIDING EXPERIENCE, PLEASE SELECT AND REPLACE THE BUSHING ACCORDING TO YOUR ACTUAL NEEDS. NOTE IMPROPER BUSHING REPLACEMENT MAY CAUSE COMPONENTS DAMAGE AND RIDER INJURY. -
Page 18: Battery Care & Charging Safety
BATTERY CARE & CHARGING SAFETY CAUTION OF FIRE AND WARNING EXPLOSION HAZARDS. SAFETY MESSAGES PROPEL EV ENDEAVOR TO PREVENT DEATH, SERIOUS INJURY OR PROPERTY DAMAGE: • Do not leave your battery unattended while charging. • If the battery has any issue when charging, stop charging and contact PROPEL EV SERVICE CENTER immediately. - Page 19 CAUTION OF FIRE AND WARNING EXPLOSION HAZARDS. SAFETY MESSAGES • Do not leave your battery unattended while charging. • Always allow the board to cool for 30 minutes before charging. Do not connect your board to the charger until the battery pack has had a chance to cool to an allowable charging temperature. •...
-
Page 20: Board Maintenance
BOARD MAINTENANCE YOU ARE RESPONSIBLE FOR ALL MAINTENANCE RELATING TO YOUR BOARD. FAILURE OF ANY PART DUE TO LACK OF MAINTENANCE IS NOT COVERED BY THE WARRANTY. NOTE CUSTOMER SERVICE If you need more help, have concerns and questions or perhaps even input, please send a detailed descrip- tion of the problem and related photos and videos to SERVICES@RIDEPROPEL.COM. -
Page 21: Warranty & Maintenance
WARRANTY MAINTENANCE 1. To give you a quick feedback, please make sure that there's the I.D. code which is on the remote, board's suspension and packing list in your email. 2. Within SIX MONTHS from the date of receipt by the user, non-human damage to the main body of the body can be repaired free of charge. -
Page 22: Performance Parameters
PERFORMANCE PARAMETERS BASIC SPECIFICATIONS LENGTH 44INCHES/1140MM WIDTH 15.4INCHES/390MM HEIGHT 9.6INCHES/245MM WHEEL SIZE 8INCHES/200MM GROUND CLEARANCE 4.4INCHES/110MM MAXIMUM PAYLOAD 330LBS/150KG 25KM/H TOP SPEED CHASSIS INDEPENDENT SUSPENSION TYRE PRESSURE 2 BAR/29PSI DECK CARBON FIBER DECK BOARD WEIGHT 40LB/18.5KG ELECTRICAL CONTROL BATTERY PACK RANGE RIDER A(75KG) 71KM, RIDER B(100KG) 50KM BATTERY SAMSUNG 25AH/1110WH,12S5P... - Page 23 WWW.RIDEPROPEL.COM EMAIL:SERVICES@RIDEPROPEL.COM / MKT@RIDEPROPEL.COM...
- Page 24 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.
