Akiles WireMac-E Operational Manual

WireMac -E
CONGRATULATIONS ON THE PURCHASE OF YOUR NEW
DUTY WIRE PUNCH AND BINDING MACHINE. YOUR
OF FUNCTION AND PREMIUM QUALITY COMPONENTS TO GUARANTEE YOU AN EFFORTLESS AND
PROFESSIONAL BIND, AS WELL AS MANY YEARS OF TROUBLE-FREE SERVICE.
WE RECOMMEND THAT YOU TAKE A FEW MINUTES TO FAMILIARIZE YOURSELF WITH THE FUNCTIONS OF
YOUR NEW
WireMac-E
ACHIEVE PROFESSIONAL RESULTS.
Closer Handle
Die Disengagement Pins
Side Margin Control
MASTER SELECTOR
Pitch
Wire Size
Wire Closure
Depth Margin
Wire Closer
Diameter Scale
Waste Drawer
Wire Snatch
A S S E M B LY & S A F E T Y I N S T R U C T I O N
1. Place your new WireMac-E on top of a sturdy working table. See picture 1
2. Plug the power cord and foot pedal cord to the back of machine See picture 2
3. Remove the screw from Closing Axle clockwise as indicated, connect the Closing Handle in a
vertical position onto the Closing Axle. Tighten-back the screws counter clockwise.
4. Turn on Power switch and press foot pedal to test punching . See picture 4.
5. Always turn switch-off and place Foot Pedal out of reach when machine is not in use.
6. To reduce the risk of electric shock, never operate the WireMac-E near water.
7. Do not use the WireMac-E if power cord is damaged.
8. Do not allow the electric cord to be in contact with hot surfaces.
9. In case of malfunction, return the unit to your distributor for service. This equipment does not contain
any part that can be serviced by the consumer or operator.
INTRODUCTION
. YOU WILL FIND THAT WITH JUST A LITTLE PRACTICE, ANY PERSON CAN
F E AT U R E S
1. 2.
O P E R A T IO N A L
WireMac-E
WireMac-E
IMPORTANT
3.
M A N U A L
, A PROFESSIONAL AND HEAVY-
WAS DESIGNED WITH A FULL RANGE
Reverse Control
Depth Margin Control
Punch Throat & Ruler
Continuous Punch Guide
Wire Closer Control
Foot Pedal Control
See picture 3.
Power Switch
4.
