Akiles AlphaCoil-E Operational Manual

TECHNICAL INFORMATION

Punching Operation
Inserting Operation
Pitch
Hole Size
Disengageable Dies
Punching Length
Punching Capacity
Binding Capacity
Weight & Volume
Warranty

WARRANTY POLICY

YOUR HAS A WARRANTY OF ONE YEAR FROM DATE OF PURCHASE. IN
THE EVENT OF A MANUFACTURER'S DEFECT, YOUR DISTRIBUTOR (AT OPTION)
WILL REPAIR OR REPLACE IT. IMPORTANT: THIS WARRANTY DOES NOT COVER
DAMAGES DUE TO IMPROPER USE OR MISTREATMENT OF THE UNIT, INCLUDING
ANY EXTRAORDINARY EVENT LEADING TO THE DAMAGE OF THE MACHINE,
WHETHER IT IS REVERSIBLE OR NOT.
IF THE IS NOT WORKING PROPERLY, FIRST FOLLOW THE CORRECTIVE
ACTIONS ABOVE. IF THE PROBLEM PERSISTS, PLEASE CONTACT YOUR DEALER
FOR FURTHER INSTRUCTIONS. PLEASE HAVE YOUR MACHINE'S SERIAL NUMBER
AND THE PURCHASE DATE READY. IF THE MACHINE MUST BE RETURNED TO YOUR
DISTRIBUTOR, IT IS YOUR RESPONSIBILITY TO PROPERLY PACK AND SHIP IT. AS
ANY DAMAGES INCURRED DURING ITS TRANSPORTATION IS NOT COVERED BY
OUR WARRANTY POLICY.
Electric (Foot Pedal / Manual Switch)
Electric (Foot Pedal)
4:1 (0.25")
Round (4mm)
All 46
Letter / A4
Up to 20 Sheets (20lb paper)
Up to 1" (Electric) / Up to 2" (Manual)
49 lbs & 1.9 CbFt
1 year
Electric Coil Punching and Inserting Binding Machine
OPERATIONAL MANUAL

INTRODUCTION

Congratulations on the purchase of your new
inserting binding machine. Your
tures, along with premium quality components to guarantee an effortless and pleasant book bind-
ing experience, as well as many years of trouble-free service.

IMPORTANT

We recommend that you take a moment to familiarize yourself with the functions of your
Make sure you read all the features and safety instructions, and follow these guidelines to install,
operate and maintain your . You will find that with just a little practice, any person can
achieve professional results.
F E ATU R E S
Coil Inserting Roller
Die Disengageable
Pins
Paper Entrance Cover
, a professional electric coil punching and
was designed with a full range of functions & safety fea-
Waste Drawer
Foot Pedal
Issue Date: April 2013
.
Function Control
(Punch/Insert)
Manual Punch
Switch
Coil Crimper Holder
Power Switch
Depth Margin
Control
