Akiles VersaMac+ Operation Manual

Semi automatic desktop punching and ejector machine

Advertisement

Quick Links

Semi Automatic Desktop Punching And Ejector Machine
Apr
2015

Advertisement

loading
Need help?

Need help?

Do you have a question about the VersaMac+ and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Akiles VersaMac+

  • Page 1 Semi Automatic Desktop Punching And Ejector Machine 2015...
  • Page 2 Assembly & Safety lnstructions Collecting Unit Setup Changing of Punch Die Troubleshooting Warranty Policy...
  • Page 3: Punch Unit

    Punch Unit Cable Socket For Auto Feeder Power Cord Socket For Auto Feeder Mode Switch Button Paper Jam Indicator Die Set Channel Paper Holder Paper Chip Container 2015...
  • Page 4: Stacker Unit

    Stacker Unit A. Screw Locker for Side Guide B. Micro-Adjusted Knob for Side Guides C. Arrow for Side Guide D. Punch Ruler Guide E. For 3R、31M Punchdie Paper Delivery Track Guide C Side Guide of Stooper Signal Connecting Cable Guide B Guide A Allen Key Wrench #8 2015...
  • Page 5 by One Person 2. Connect the Punch Unit and Collecting Unit by locking 3 screws and attaching the connection cable. Pedal Punch Stacker Unit 11. Never fix the by hand without powering off the unit and unplugging the power cord. 12.
  • Page 6 3. More punch patterns may be available.Contact your dealer for our most up to date list of punch patterns. 2015...
  • Page 7 5. Make the appropriate adjustment to select the Depth Margin position best suited for your job. There are 4 available depth margin positions in each punch die (2mm, 3mm, 4mm and 5mm from edge of paper to the nearest edge of hole).Adjustments can be done by PULLING or PUSHING the Depth Margin Control Bar towards the LEFT or RIGHT side of the machine.See Picture 4 2015...
  • Page 8 To avoid partially punched holes,follow the simple steps below to disengage (remove) the corresponding punch pin in the die set. For most standard sheet sizes,you can easily find the holes that need to be disengaged (removed) from the Punch Ruler Guide label on each die. Just look for the sheet size that you are using, and identify the appropriate punch pin that will create a partial punched hole in your sheet.
  • Page 9 See Picture 1 power See Picture 2 See Picture 3 Line up here for 14”punch. Line up here for 41 OVAL punch. Maximum single punch capacity of 25 sheets (20 lb paper). The number 3R、31M Punch die of sheets depends on the 3.
  • Page 10 Stacker Unit Setup 1. position guide a.b by different sheet size . See Picture 1 Guide B Guide A 2. Lift paper delivery guide. See Picture 2 Paper Delivery Guide 3. Adjust paper stopper to match the size of the punched paper. See Picture 3 Paper Stopper 4.
  • Page 11 switch See Picture 1 s f ll See Picture 2 See Picture 3 See Picture 4 See Picture 5 See Picture 6 2015...
  • Page 12 2015...
  • Page 13: Troubleshooting

    TROUBLESHOOTING remove the power cord from the machine. #8 Allen Key Wrench #8 Allen Key Wrench #8 Allen Key Wrench #8 Allen Key Wrench 2015...
  • Page 14 The Power Indicator Light on the Control Panel is ON. The Die-In Indicator Light on the Control Panel is ON. #8 Allen Key Wrench #8 Allen Key Wrench and the correct mode is selected. Punch again with reduced number of sheets. overflowed.
  • Page 15 MISUSED Apr. 2015...
